AirTAC 3V Series · 3/2-Way Solenoid Valve Manifold
AirTAC 3V2M 3/2-Way Solenoid Valve Manifold Set, 1/8" Port
Every stocked AirTAC 3V2M valve manifold set configuration on one page: 403 order codes with 1/8" ports, from $50.24. Pick the coil voltage, valve type · entry and stations · exhaust · thread to see the exact order code and price.
This combination is not a stock order code. Request a quote and we will confirm availability and price.
$50.24
$55.18Save 8%
Request a Quote
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC 3V2M
The AirTAC 3V2M valve manifold set is a ready-made set of identical 3V2M direct-acting 3/2-way valves (NC / NO) on a common base, 1 to 20 stations. It has 1/8" ports (PT thread as standard, NPT also stocked). It works from 0 to 0.8 MPa (0-114 psi), on air filtered to 40 µm.
It is direct-acting with a coaxial poppet that seals well, switches quickly and needs no lubrication; a manual override helps setup. Valves mount on a common base with one air supply and one wiring run, so faults are easy to trace, and stations can be combined or extended freely. The base uses a dedicated gasket: turning the gasket over does not convert a valve between NC and NO. Flow: 1.7 mm² (Cv 0.1). The coil is rated IP65 with class B insulation, responds in 0.05 s or less, and runs up to 10 cycles per second.
3V2M Technical Specifications
| Model | 3V2M |
|---|---|
| Function | 3/2-way, direct-acting, single solenoid, spring return |
| Valve type | NC / NO |
| Port | 1/8" |
| Flow | 1.7 mm² (Cv 0.1) |
| Stations | 1 – 20 |
| Exhaust | Common or individual (D) |
| Fluid | Air (filtered by 40 µm element) |
|---|---|
| Operating pressure | 0 – 0.8 MPa (0 – 114 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to +70 °C |
| Coil power | AC 7 VA · DC 7.0 W |
| Voltage tolerance | AC ±15%, DC ±10% |
| Protection / insulation | IP65 (DIN40050) / class B |
| Response / max frequency | 0.05 s or less / 10 cycles/s |
| Body | Aluminum alloy |
Source: AirTAC Products Catalog 2026A (PDF01-P0042), 3V2M series specifications and ordering code. Lubrication is not required.
How the 3V2M Order Code Is Built
| 3V2M | Base-mounted series |
|---|---|
| NC / NO | Normally closed / normally open |
| A / B / C / E / F | Voltage: A AC220V, B DC24V, C AC110V, E AC24V, F DC12V |
| I | Lead wire 0.5 m (blank = DIN connector) |
| -1F – 20F | Number of stations |
| D | Individual exhaust (blank = common) |
| G / T | Thread: G = G, T = NPT, blank = PT |
All AirTAC 3V2M Order Codes (403)
Each order code links to its own datasheet page. Use Select to load it into the configurator above.
| Order code | Voltage | Type · entry | Stations · exhaust · thread | Price | Select |
|---|---|---|---|---|---|
| 3V2MNCB-1F | DC24V (B) | NC · DIN connector | 1 station · common exhaust · PT thread | $50.24 | |
| 3V2MNCB-2F | DC24V (B) | NC · DIN connector | 2 stations · common exhaust · PT thread | $90.40 | |
| 3V2MNCB-3F | DC24V (B) | NC · DIN connector | 3 stations · common exhaust · PT thread | $130.60 | |
| 3V2MNCB-4F | DC24V (B) | NC · DIN connector | 4 stations · common exhaust · PT thread | $170.76 | |
| 3V2MNCB-5F | DC24V (B) | NC · DIN connector | 5 stations · common exhaust · PT thread | $210.97 | |
| 3V2MNCB-6F | DC24V (B) | NC · DIN connector | 6 stations · common exhaust · PT thread | $251.12 | |
| 3V2MNCB-6FD | DC24V (B) | NC · DIN connector | 6 stations · individual exhaust (D) · PT thread | $251.12 | |
| 3V2MNCB-7F | DC24V (B) | NC · DIN connector | 7 stations · common exhaust · PT thread | $291.33 | |
| 3V2MNCB-8F | DC24V (B) | NC · DIN connector | 8 stations · common exhaust · PT thread | $331.48 | |
| 3V2MNCB-8FD | DC24V (B) | NC · DIN connector | 8 stations · individual exhaust (D) · PT thread | $331.48 | |
| 3V2MNCB-9F | DC24V (B) | NC · DIN connector | 9 stations · common exhaust · PT thread | $371.69 | |
| 3V2MNCB-10F | DC24V (B) | NC · DIN connector | 10 stations · common exhaust · PT thread | $411.85 | |
| 3V2MNCB-11F | DC24V (B) | NC · DIN connector | 11 stations · common exhaust · PT thread | $452.05 | |
| 3V2MNCB-12F | DC24V (B) | NC · DIN connector | 12 stations · common exhaust · PT thread | $492.21 | |
| 3V2MNCB-13F | DC24V (B) | NC · DIN connector | 13 stations · common exhaust · PT thread | $532.41 | |
| 3V2MNCB-14F | DC24V (B) | NC · DIN connector | 14 stations · common exhaust · PT thread | $572.57 | |
| 3V2MNCB-15F | DC24V (B) | NC · DIN connector | 15 stations · common exhaust · PT thread | $612.77 | |
| 3V2MNCB-16F | DC24V (B) | NC · DIN connector | 16 stations · common exhaust · PT thread | $652.93 | |
| 3V2MNCB-17F | DC24V (B) | NC · DIN connector | 17 stations · common exhaust · PT thread | $693.14 | |
| 3V2MNCB-18F | DC24V (B) | NC · DIN connector | 18 stations · common exhaust · PT thread | $733.29 | |
| 3V2MNCB-19F | DC24V (B) | NC · DIN connector | 19 stations · common exhaust · PT thread | $773.50 | |
| 3V2MNCB-20F | DC24V (B) | NC · DIN connector | 20 stations · common exhaust · PT thread | $813.65 | |
| 3V2MNCBI-1F | DC24V (B) | NC · Lead wire 0.5 m (I) | 1 station · common exhaust · PT thread | $50.24 | |
| 3V2MNCBI-2F | DC24V (B) | NC · Lead wire 0.5 m (I) | 2 stations · common exhaust · PT thread | $90.40 | |
| 3V2MNCBI-3F | DC24V (B) | NC · Lead wire 0.5 m (I) | 3 stations · common exhaust · PT thread | $130.60 | |
| 3V2MNCBI-4F | DC24V (B) | NC · Lead wire 0.5 m (I) | 4 stations · common exhaust · PT thread | $170.76 | |
| 3V2MNCBI-5F | DC24V (B) | NC · Lead wire 0.5 m (I) | 5 stations · common exhaust · PT thread | $210.97 | |
| 3V2MNCBI-6F | DC24V (B) | NC · Lead wire 0.5 m (I) | 6 stations · common exhaust · PT thread | $251.12 | |
| 3V2MNCBI-6FDT | DC24V (B) | NC · Lead wire 0.5 m (I) | 6 stations · individual exhaust (D) · NPT thread | $390.38 | |
| 3V2MNCBI-7F | DC24V (B) | NC · Lead wire 0.5 m (I) | 7 stations · common exhaust · PT thread | $291.33 | |
| 3V2MNCBI-8F | DC24V (B) | NC · Lead wire 0.5 m (I) | 8 stations · common exhaust · PT thread | $331.48 | |
| 3V2MNCBI-9F | DC24V (B) | NC · Lead wire 0.5 m (I) | 9 stations · common exhaust · PT thread | $371.69 | |
| 3V2MNCBI-10F | DC24V (B) | NC · Lead wire 0.5 m (I) | 10 stations · common exhaust · PT thread | $411.85 | |
| 3V2MNCBI-11F | DC24V (B) | NC · Lead wire 0.5 m (I) | 11 stations · common exhaust · PT thread | $452.05 | |
| 3V2MNCBI-12F | DC24V (B) | NC · Lead wire 0.5 m (I) | 12 stations · common exhaust · PT thread | $492.21 | |
| 3V2MNCBI-13F | DC24V (B) | NC · Lead wire 0.5 m (I) | 13 stations · common exhaust · PT thread | $532.41 | |
| 3V2MNCBI-14F | DC24V (B) | NC · Lead wire 0.5 m (I) | 14 stations · common exhaust · PT thread | $572.57 | |
| 3V2MNCBI-15F | DC24V (B) | NC · Lead wire 0.5 m (I) | 15 stations · common exhaust · PT thread | $612.77 | |
| 3V2MNCBI-16F | DC24V (B) | NC · Lead wire 0.5 m (I) | 16 stations · common exhaust · PT thread | $652.93 | |
| 3V2MNCBI-17F | DC24V (B) | NC · Lead wire 0.5 m (I) | 17 stations · common exhaust · PT thread | $693.14 | |
| 3V2MNCBI-18F | DC24V (B) | NC · Lead wire 0.5 m (I) | 18 stations · common exhaust · PT thread | $733.29 | |
| 3V2MNCBI-19F | DC24V (B) | NC · Lead wire 0.5 m (I) | 19 stations · common exhaust · PT thread | $773.50 | |
| 3V2MNCBI-20F | DC24V (B) | NC · Lead wire 0.5 m (I) | 20 stations · common exhaust · PT thread | $813.65 | |
| 3V2MNOB-1F | DC24V (B) | NO · DIN connector | 1 station · common exhaust · PT thread | $50.24 | |
| 3V2MNOB-2F | DC24V (B) | NO · DIN connector | 2 stations · common exhaust · PT thread | $90.40 | |
| 3V2MNOB-3F | DC24V (B) | NO · DIN connector | 3 stations · common exhaust · PT thread | $130.60 | |
| 3V2MNOB-4F | DC24V (B) | NO · DIN connector | 4 stations · common exhaust · PT thread | $170.76 | |
| 3V2MNOB-5F | DC24V (B) | NO · DIN connector | 5 stations · common exhaust · PT thread | $210.97 | |
| 3V2MNOB-6F | DC24V (B) | NO · DIN connector | 6 stations · common exhaust · PT thread | $251.12 | |
| 3V2MNOB-7F | DC24V (B) | NO · DIN connector | 7 stations · common exhaust · PT thread | $291.33 | |
| 3V2MNOB-8F | DC24V (B) | NO · DIN connector | 8 stations · common exhaust · PT thread | $331.48 | |
| 3V2MNOB-9F | DC24V (B) | NO · DIN connector | 9 stations · common exhaust · PT thread | $371.69 | |
| 3V2MNOB-10F | DC24V (B) | NO · DIN connector | 10 stations · common exhaust · PT thread | $411.85 | |
| 3V2MNOB-11F | DC24V (B) | NO · DIN connector | 11 stations · common exhaust · PT thread | $452.05 | |
| 3V2MNOB-12F | DC24V (B) | NO · DIN connector | 12 stations · common exhaust · PT thread | $492.21 | |
| 3V2MNOB-13F | DC24V (B) | NO · DIN connector | 13 stations · common exhaust · PT thread | $532.41 | |
| 3V2MNOB-14F | DC24V (B) | NO · DIN connector | 14 stations · common exhaust · PT thread | $572.57 | |
| 3V2MNOB-15F | DC24V (B) | NO · DIN connector | 15 stations · common exhaust · PT thread | $612.77 | |
| 3V2MNOB-16F | DC24V (B) | NO · DIN connector | 16 stations · common exhaust · PT thread | $652.93 | |
| 3V2MNOB-17F | DC24V (B) | NO · DIN connector | 17 stations · common exhaust · PT thread | $693.14 | |
| 3V2MNOB-18F | DC24V (B) | NO · DIN connector | 18 stations · common exhaust · PT thread | $733.29 | |
| 3V2MNOB-19F | DC24V (B) | NO · DIN connector | 19 stations · common exhaust · PT thread | $773.50 | |
| 3V2MNOB-20F | DC24V (B) | NO · DIN connector | 20 stations · common exhaust · PT thread | $813.65 | |
| 3V2MNOBI-1F | DC24V (B) | NO · Lead wire 0.5 m (I) | 1 station · common exhaust · PT thread | $50.24 | |
| 3V2MNOBI-2F | DC24V (B) | NO · Lead wire 0.5 m (I) | 2 stations · common exhaust · PT thread | $90.40 | |
| 3V2MNOBI-3F | DC24V (B) | NO · Lead wire 0.5 m (I) | 3 stations · common exhaust · PT thread | $130.60 | |
| 3V2MNOBI-4F | DC24V (B) | NO · Lead wire 0.5 m (I) | 4 stations · common exhaust · PT thread | $170.76 | |
| 3V2MNOBI-5F | DC24V (B) | NO · Lead wire 0.5 m (I) | 5 stations · common exhaust · PT thread | $210.97 | |
| 3V2MNOBI-6F | DC24V (B) | NO · Lead wire 0.5 m (I) | 6 stations · common exhaust · PT thread | $251.12 | |
| 3V2MNOBI-7F | DC24V (B) | NO · Lead wire 0.5 m (I) | 7 stations · common exhaust · PT thread | $291.33 | |
| 3V2MNOBI-8F | DC24V (B) | NO · Lead wire 0.5 m (I) | 8 stations · common exhaust · PT thread | $331.48 | |
| 3V2MNOBI-9F | DC24V (B) | NO · Lead wire 0.5 m (I) | 9 stations · common exhaust · PT thread | $371.69 | |
| 3V2MNOBI-10F | DC24V (B) | NO · Lead wire 0.5 m (I) | 10 stations · common exhaust · PT thread | $411.85 | |
| 3V2MNOBI-11F | DC24V (B) | NO · Lead wire 0.5 m (I) | 11 stations · common exhaust · PT thread | $452.05 | |
| 3V2MNOBI-12F | DC24V (B) | NO · Lead wire 0.5 m (I) | 12 stations · common exhaust · PT thread | $492.21 | |
| 3V2MNOBI-13F | DC24V (B) | NO · Lead wire 0.5 m (I) | 13 stations · common exhaust · PT thread | $532.41 | |
| 3V2MNOBI-14F | DC24V (B) | NO · Lead wire 0.5 m (I) | 14 stations · common exhaust · PT thread | $572.57 | |
| 3V2MNOBI-15F | DC24V (B) | NO · Lead wire 0.5 m (I) | 15 stations · common exhaust · PT thread | $612.77 | |
| 3V2MNOBI-16F | DC24V (B) | NO · Lead wire 0.5 m (I) | 16 stations · common exhaust · PT thread | $652.93 | |
| 3V2MNOBI-17F | DC24V (B) | NO · Lead wire 0.5 m (I) | 17 stations · common exhaust · PT thread | $693.14 | |
| 3V2MNOBI-18F | DC24V (B) | NO · Lead wire 0.5 m (I) | 18 stations · common exhaust · PT thread | $733.29 | |
| 3V2MNOBI-19F | DC24V (B) | NO · Lead wire 0.5 m (I) | 19 stations · common exhaust · PT thread | $773.50 | |
| 3V2MNOBI-20F | DC24V (B) | NO · Lead wire 0.5 m (I) | 20 stations · common exhaust · PT thread | $813.65 | |
| 3V2MNCA-1F | AC220V (A) | NC · DIN connector | 1 station · common exhaust · PT thread | $50.24 | |
| 3V2MNCA-2F | AC220V (A) | NC · DIN connector | 2 stations · common exhaust · PT thread | $90.40 | |
| 3V2MNCA-3F | AC220V (A) | NC · DIN connector | 3 stations · common exhaust · PT thread | $130.60 | |
| 3V2MNCA-4F | AC220V (A) | NC · DIN connector | 4 stations · common exhaust · PT thread | $170.76 | |
| 3V2MNCA-5F | AC220V (A) | NC · DIN connector | 5 stations · common exhaust · PT thread | $210.97 | |
| 3V2MNCA-6F | AC220V (A) | NC · DIN connector | 6 stations · common exhaust · PT thread | $251.12 | |
| 3V2MNCA-7F | AC220V (A) | NC · DIN connector | 7 stations · common exhaust · PT thread | $291.33 | |
| 3V2MNCA-8F | AC220V (A) | NC · DIN connector | 8 stations · common exhaust · PT thread | $331.48 | |
| 3V2MNCA-9F | AC220V (A) | NC · DIN connector | 9 stations · common exhaust · PT thread | $371.69 | |
| 3V2MNCA-10F | AC220V (A) | NC · DIN connector | 10 stations · common exhaust · PT thread | $411.85 | |
| 3V2MNCA-11F | AC220V (A) | NC · DIN connector | 11 stations · common exhaust · PT thread | $452.05 | |
| 3V2MNCA-12F | AC220V (A) | NC · DIN connector | 12 stations · common exhaust · PT thread | $492.21 | |
| 3V2MNCA-13F | AC220V (A) | NC · DIN connector | 13 stations · common exhaust · PT thread | $532.41 | |
| 3V2MNCA-14F | AC220V (A) | NC · DIN connector | 14 stations · common exhaust · PT thread | $572.57 | |
| 3V2MNCA-15F | AC220V (A) | NC · DIN connector | 15 stations · common exhaust · PT thread | $612.77 | |
| 3V2MNCA-16F | AC220V (A) | NC · DIN connector | 16 stations · common exhaust · PT thread | $652.93 | |
| 3V2MNCA-17F | AC220V (A) | NC · DIN connector | 17 stations · common exhaust · PT thread | $693.14 | |
| 3V2MNCA-18F | AC220V (A) | NC · DIN connector | 18 stations · common exhaust · PT thread | $733.29 | |
| 3V2MNCA-19F | AC220V (A) | NC · DIN connector | 19 stations · common exhaust · PT thread | $773.50 | |
| 3V2MNCA-20F | AC220V (A) | NC · DIN connector | 20 stations · common exhaust · PT thread | $813.65 | |
| 3V2MNCAI-1F | AC220V (A) | NC · Lead wire 0.5 m (I) | 1 station · common exhaust · PT thread | $50.24 | |
| 3V2MNCAI-2F | AC220V (A) | NC · Lead wire 0.5 m (I) | 2 stations · common exhaust · PT thread | $90.40 | |
| 3V2MNCAI-3F | AC220V (A) | NC · Lead wire 0.5 m (I) | 3 stations · common exhaust · PT thread | $130.60 | |
| 3V2MNCAI-4F | AC220V (A) | NC · Lead wire 0.5 m (I) | 4 stations · common exhaust · PT thread | $170.76 | |
| 3V2MNCAI-5F | AC220V (A) | NC · Lead wire 0.5 m (I) | 5 stations · common exhaust · PT thread | $210.97 | |
| 3V2MNCAI-6F | AC220V (A) | NC · Lead wire 0.5 m (I) | 6 stations · common exhaust · PT thread | $251.12 | |
| 3V2MNCAI-7F | AC220V (A) | NC · Lead wire 0.5 m (I) | 7 stations · common exhaust · PT thread | $291.33 | |
| 3V2MNCAI-8F | AC220V (A) | NC · Lead wire 0.5 m (I) | 8 stations · common exhaust · PT thread | $331.48 | |
| 3V2MNCAI-9F | AC220V (A) | NC · Lead wire 0.5 m (I) | 9 stations · common exhaust · PT thread | $371.69 | |
| 3V2MNCAI-10F | AC220V (A) | NC · Lead wire 0.5 m (I) | 10 stations · common exhaust · PT thread | $411.85 | |
| 3V2MNCAI-11F | AC220V (A) | NC · Lead wire 0.5 m (I) | 11 stations · common exhaust · PT thread | $452.05 | |
| 3V2MNCAI-12F | AC220V (A) | NC · Lead wire 0.5 m (I) | 12 stations · common exhaust · PT thread | $492.21 | |
| 3V2MNCAI-13F | AC220V (A) | NC · Lead wire 0.5 m (I) | 13 stations · common exhaust · PT thread | $532.41 | |
| 3V2MNCAI-14F | AC220V (A) | NC · Lead wire 0.5 m (I) | 14 stations · common exhaust · PT thread | $572.57 | |
| 3V2MNCAI-15F | AC220V (A) | NC · Lead wire 0.5 m (I) | 15 stations · common exhaust · PT thread | $612.77 | |
| 3V2MNCAI-16F | AC220V (A) | NC · Lead wire 0.5 m (I) | 16 stations · common exhaust · PT thread | $652.93 | |
| 3V2MNCAI-17F | AC220V (A) | NC · Lead wire 0.5 m (I) | 17 stations · common exhaust · PT thread | $693.14 | |
| 3V2MNCAI-18F | AC220V (A) | NC · Lead wire 0.5 m (I) | 18 stations · common exhaust · PT thread | $733.29 | |
| 3V2MNCAI-19F | AC220V (A) | NC · Lead wire 0.5 m (I) | 19 stations · common exhaust · PT thread | $773.50 | |
| 3V2MNCAI-20F | AC220V (A) | NC · Lead wire 0.5 m (I) | 20 stations · common exhaust · PT thread | $813.65 | |
| 3V2MNOA-1F | AC220V (A) | NO · DIN connector | 1 station · common exhaust · PT thread | $50.24 | |
| 3V2MNOA-2F | AC220V (A) | NO · DIN connector | 2 stations · common exhaust · PT thread | $90.40 | |
| 3V2MNOA-3F | AC220V (A) | NO · DIN connector | 3 stations · common exhaust · PT thread | $130.60 | |
| 3V2MNOA-4F | AC220V (A) | NO · DIN connector | 4 stations · common exhaust · PT thread | $170.76 | |
| 3V2MNOA-5F | AC220V (A) | NO · DIN connector | 5 stations · common exhaust · PT thread | $210.97 | |
| 3V2MNOA-6F | AC220V (A) | NO · DIN connector | 6 stations · common exhaust · PT thread | $251.12 | |
| 3V2MNOA-7F | AC220V (A) | NO · DIN connector | 7 stations · common exhaust · PT thread | $291.33 | |
| 3V2MNOA-8F | AC220V (A) | NO · DIN connector | 8 stations · common exhaust · PT thread | $331.48 | |
| 3V2MNOA-9F | AC220V (A) | NO · DIN connector | 9 stations · common exhaust · PT thread | $371.69 | |
| 3V2MNOA-10F | AC220V (A) | NO · DIN connector | 10 stations · common exhaust · PT thread | $411.85 | |
| 3V2MNOA-11F | AC220V (A) | NO · DIN connector | 11 stations · common exhaust · PT thread | $452.05 | |
| 3V2MNOA-12F | AC220V (A) | NO · DIN connector | 12 stations · common exhaust · PT thread | $492.21 | |
| 3V2MNOA-13F | AC220V (A) | NO · DIN connector | 13 stations · common exhaust · PT thread | $532.41 | |
| 3V2MNOA-14F | AC220V (A) | NO · DIN connector | 14 stations · common exhaust · PT thread | $572.57 | |
| 3V2MNOA-15F | AC220V (A) | NO · DIN connector | 15 stations · common exhaust · PT thread | $612.77 | |
| 3V2MNOA-16F | AC220V (A) | NO · DIN connector | 16 stations · common exhaust · PT thread | $652.93 | |
| 3V2MNOA-17F | AC220V (A) | NO · DIN connector | 17 stations · common exhaust · PT thread | $693.14 | |
| 3V2MNOA-18F | AC220V (A) | NO · DIN connector | 18 stations · common exhaust · PT thread | $733.29 | |
| 3V2MNOA-19F | AC220V (A) | NO · DIN connector | 19 stations · common exhaust · PT thread | $773.50 | |
| 3V2MNOA-20F | AC220V (A) | NO · DIN connector | 20 stations · common exhaust · PT thread | $813.65 | |
| 3V2MNOAI-1F | AC220V (A) | NO · Lead wire 0.5 m (I) | 1 station · common exhaust · PT thread | $50.24 | |
| 3V2MNOAI-2F | AC220V (A) | NO · Lead wire 0.5 m (I) | 2 stations · common exhaust · PT thread | $90.40 | |
| 3V2MNOAI-3F | AC220V (A) | NO · Lead wire 0.5 m (I) | 3 stations · common exhaust · PT thread | $130.60 | |
| 3V2MNOAI-4F | AC220V (A) | NO · Lead wire 0.5 m (I) | 4 stations · common exhaust · PT thread | $170.76 | |
| 3V2MNOAI-5F | AC220V (A) | NO · Lead wire 0.5 m (I) | 5 stations · common exhaust · PT thread | $210.97 | |
| 3V2MNOAI-6F | AC220V (A) | NO · Lead wire 0.5 m (I) | 6 stations · common exhaust · PT thread | $251.12 | |
| 3V2MNOAI-7F | AC220V (A) | NO · Lead wire 0.5 m (I) | 7 stations · common exhaust · PT thread | $291.33 | |
| 3V2MNOAI-8F | AC220V (A) | NO · Lead wire 0.5 m (I) | 8 stations · common exhaust · PT thread | $331.48 | |
| 3V2MNOAI-9F | AC220V (A) | NO · Lead wire 0.5 m (I) | 9 stations · common exhaust · PT thread | $371.69 | |
| 3V2MNOAI-10F | AC220V (A) | NO · Lead wire 0.5 m (I) | 10 stations · common exhaust · PT thread | $411.85 | |
| 3V2MNOAI-11F | AC220V (A) | NO · Lead wire 0.5 m (I) | 11 stations · common exhaust · PT thread | $452.05 | |
| 3V2MNOAI-12F | AC220V (A) | NO · Lead wire 0.5 m (I) | 12 stations · common exhaust · PT thread | $492.21 | |
| 3V2MNOAI-13F | AC220V (A) | NO · Lead wire 0.5 m (I) | 13 stations · common exhaust · PT thread | $532.41 | |
| 3V2MNOAI-14F | AC220V (A) | NO · Lead wire 0.5 m (I) | 14 stations · common exhaust · PT thread | $572.57 | |
| 3V2MNOAI-15F | AC220V (A) | NO · Lead wire 0.5 m (I) | 15 stations · common exhaust · PT thread | $612.77 | |
| 3V2MNOAI-16F | AC220V (A) | NO · Lead wire 0.5 m (I) | 16 stations · common exhaust · PT thread | $652.93 | |
| 3V2MNOAI-17F | AC220V (A) | NO · Lead wire 0.5 m (I) | 17 stations · common exhaust · PT thread | $693.14 | |
| 3V2MNOAI-18F | AC220V (A) | NO · Lead wire 0.5 m (I) | 18 stations · common exhaust · PT thread | $733.29 | |
| 3V2MNOAI-19F | AC220V (A) | NO · Lead wire 0.5 m (I) | 19 stations · common exhaust · PT thread | $773.50 | |
| 3V2MNOAI-20F | AC220V (A) | NO · Lead wire 0.5 m (I) | 20 stations · common exhaust · PT thread | $813.65 | |
| 3V2MNCC-1F | AC110V (C) | NC · DIN connector | 1 station · common exhaust · PT thread | $50.24 | |
| 3V2MNCC-2F | AC110V (C) | NC · DIN connector | 2 stations · common exhaust · PT thread | $90.40 | |
| 3V2MNCC-3F | AC110V (C) | NC · DIN connector | 3 stations · common exhaust · PT thread | $130.60 | |
| 3V2MNCC-4F | AC110V (C) | NC · DIN connector | 4 stations · common exhaust · PT thread | $170.76 | |
| 3V2MNCC-5F | AC110V (C) | NC · DIN connector | 5 stations · common exhaust · PT thread | $210.97 | |
| 3V2MNCC-6F | AC110V (C) | NC · DIN connector | 6 stations · common exhaust · PT thread | $251.12 | |
| 3V2MNCC-7F | AC110V (C) | NC · DIN connector | 7 stations · common exhaust · PT thread | $291.33 | |
| 3V2MNCC-8F | AC110V (C) | NC · DIN connector | 8 stations · common exhaust · PT thread | $331.48 | |
| 3V2MNCC-9F | AC110V (C) | NC · DIN connector | 9 stations · common exhaust · PT thread | $371.69 | |
| 3V2MNCC-10F | AC110V (C) | NC · DIN connector | 10 stations · common exhaust · PT thread | $411.85 | |
| 3V2MNCC-11F | AC110V (C) | NC · DIN connector | 11 stations · common exhaust · PT thread | $452.05 | |
| 3V2MNCC-12F | AC110V (C) | NC · DIN connector | 12 stations · common exhaust · PT thread | $492.21 | |
| 3V2MNCC-13F | AC110V (C) | NC · DIN connector | 13 stations · common exhaust · PT thread | $532.41 | |
| 3V2MNCC-14F | AC110V (C) | NC · DIN connector | 14 stations · common exhaust · PT thread | $572.57 | |
| 3V2MNCC-15F | AC110V (C) | NC · DIN connector | 15 stations · common exhaust · PT thread | $612.77 | |
| 3V2MNCC-16F | AC110V (C) | NC · DIN connector | 16 stations · common exhaust · PT thread | $652.93 | |
| 3V2MNCC-17F | AC110V (C) | NC · DIN connector | 17 stations · common exhaust · PT thread | $693.14 | |
| 3V2MNCC-18F | AC110V (C) | NC · DIN connector | 18 stations · common exhaust · PT thread | $733.29 | |
| 3V2MNCC-19F | AC110V (C) | NC · DIN connector | 19 stations · common exhaust · PT thread | $773.50 | |
| 3V2MNCC-20F | AC110V (C) | NC · DIN connector | 20 stations · common exhaust · PT thread | $813.65 | |
| 3V2MNCCI-1F | AC110V (C) | NC · Lead wire 0.5 m (I) | 1 station · common exhaust · PT thread | $50.24 | |
| 3V2MNCCI-2F | AC110V (C) | NC · Lead wire 0.5 m (I) | 2 stations · common exhaust · PT thread | $90.40 | |
| 3V2MNCCI-3F | AC110V (C) | NC · Lead wire 0.5 m (I) | 3 stations · common exhaust · PT thread | $130.60 | |
| 3V2MNCCI-4F | AC110V (C) | NC · Lead wire 0.5 m (I) | 4 stations · common exhaust · PT thread | $170.76 | |
| 3V2MNCCI-5F | AC110V (C) | NC · Lead wire 0.5 m (I) | 5 stations · common exhaust · PT thread | $210.97 | |
| 3V2MNCCI-6F | AC110V (C) | NC · Lead wire 0.5 m (I) | 6 stations · common exhaust · PT thread | $251.12 | |
| 3V2MNCCI-7F | AC110V (C) | NC · Lead wire 0.5 m (I) | 7 stations · common exhaust · PT thread | $291.33 | |
| 3V2MNCCI-8F | AC110V (C) | NC · Lead wire 0.5 m (I) | 8 stations · common exhaust · PT thread | $331.48 | |
| 3V2MNCCI-9F | AC110V (C) | NC · Lead wire 0.5 m (I) | 9 stations · common exhaust · PT thread | $371.69 | |
| 3V2MNCCI-10F | AC110V (C) | NC · Lead wire 0.5 m (I) | 10 stations · common exhaust · PT thread | $411.85 | |
| 3V2MNCCI-11F | AC110V (C) | NC · Lead wire 0.5 m (I) | 11 stations · common exhaust · PT thread | $452.05 | |
| 3V2MNCCI-12F | AC110V (C) | NC · Lead wire 0.5 m (I) | 12 stations · common exhaust · PT thread | $492.21 | |
| 3V2MNCCI-13F | AC110V (C) | NC · Lead wire 0.5 m (I) | 13 stations · common exhaust · PT thread | $532.41 | |
| 3V2MNCCI-14F | AC110V (C) | NC · Lead wire 0.5 m (I) | 14 stations · common exhaust · PT thread | $572.57 | |
| 3V2MNCCI-15F | AC110V (C) | NC · Lead wire 0.5 m (I) | 15 stations · common exhaust · PT thread | $612.77 | |
| 3V2MNCCI-16F | AC110V (C) | NC · Lead wire 0.5 m (I) | 16 stations · common exhaust · PT thread | $652.93 | |
| 3V2MNCCI-17F | AC110V (C) | NC · Lead wire 0.5 m (I) | 17 stations · common exhaust · PT thread | $693.14 | |
| 3V2MNCCI-18F | AC110V (C) | NC · Lead wire 0.5 m (I) | 18 stations · common exhaust · PT thread | $733.29 | |
| 3V2MNCCI-19F | AC110V (C) | NC · Lead wire 0.5 m (I) | 19 stations · common exhaust · PT thread | $773.50 | |
| 3V2MNCCI-20F | AC110V (C) | NC · Lead wire 0.5 m (I) | 20 stations · common exhaust · PT thread | $813.65 | |
| 3V2MNOC-1F | AC110V (C) | NO · DIN connector | 1 station · common exhaust · PT thread | $50.24 | |
| 3V2MNOC-2F | AC110V (C) | NO · DIN connector | 2 stations · common exhaust · PT thread | $90.40 | |
| 3V2MNOC-3F | AC110V (C) | NO · DIN connector | 3 stations · common exhaust · PT thread | $130.60 | |
| 3V2MNOC-4F | AC110V (C) | NO · DIN connector | 4 stations · common exhaust · PT thread | $170.76 | |
| 3V2MNOC-5F | AC110V (C) | NO · DIN connector | 5 stations · common exhaust · PT thread | $210.97 | |
| 3V2MNOC-6F | AC110V (C) | NO · DIN connector | 6 stations · common exhaust · PT thread | $251.12 | |
| 3V2MNOC-7F | AC110V (C) | NO · DIN connector | 7 stations · common exhaust · PT thread | $291.33 | |
| 3V2MNOC-8F | AC110V (C) | NO · DIN connector | 8 stations · common exhaust · PT thread | $331.48 | |
| 3V2MNOC-9F | AC110V (C) | NO · DIN connector | 9 stations · common exhaust · PT thread | $371.69 | |
| 3V2MNOC-10F | AC110V (C) | NO · DIN connector | 10 stations · common exhaust · PT thread | $411.85 | |
| 3V2MNOC-11F | AC110V (C) | NO · DIN connector | 11 stations · common exhaust · PT thread | $452.05 | |
| 3V2MNOC-12F | AC110V (C) | NO · DIN connector | 12 stations · common exhaust · PT thread | $492.21 | |
| 3V2MNOC-13F | AC110V (C) | NO · DIN connector | 13 stations · common exhaust · PT thread | $532.41 | |
| 3V2MNOC-14F | AC110V (C) | NO · DIN connector | 14 stations · common exhaust · PT thread | $572.57 | |
| 3V2MNOC-15F | AC110V (C) | NO · DIN connector | 15 stations · common exhaust · PT thread | $612.77 | |
| 3V2MNOC-16F | AC110V (C) | NO · DIN connector | 16 stations · common exhaust · PT thread | $652.93 | |
| 3V2MNOC-17F | AC110V (C) | NO · DIN connector | 17 stations · common exhaust · PT thread | $693.14 | |
| 3V2MNOC-18F | AC110V (C) | NO · DIN connector | 18 stations · common exhaust · PT thread | $733.29 | |
| 3V2MNOC-19F | AC110V (C) | NO · DIN connector | 19 stations · common exhaust · PT thread | $773.50 | |
| 3V2MNOC-20F | AC110V (C) | NO · DIN connector | 20 stations · common exhaust · PT thread | $813.65 | |
| 3V2MNOCI-1F | AC110V (C) | NO · Lead wire 0.5 m (I) | 1 station · common exhaust · PT thread | $50.24 | |
| 3V2MNOCI-2F | AC110V (C) | NO · Lead wire 0.5 m (I) | 2 stations · common exhaust · PT thread | $90.40 | |
| 3V2MNOCI-3F | AC110V (C) | NO · Lead wire 0.5 m (I) | 3 stations · common exhaust · PT thread | $130.60 | |
| 3V2MNOCI-4F | AC110V (C) | NO · Lead wire 0.5 m (I) | 4 stations · common exhaust · PT thread | $170.76 | |
| 3V2MNOCI-5F | AC110V (C) | NO · Lead wire 0.5 m (I) | 5 stations · common exhaust · PT thread | $210.97 | |
| 3V2MNOCI-6F | AC110V (C) | NO · Lead wire 0.5 m (I) | 6 stations · common exhaust · PT thread | $251.12 | |
| 3V2MNOCI-7F | AC110V (C) | NO · Lead wire 0.5 m (I) | 7 stations · common exhaust · PT thread | $291.33 | |
| 3V2MNOCI-8F | AC110V (C) | NO · Lead wire 0.5 m (I) | 8 stations · common exhaust · PT thread | $331.48 | |
| 3V2MNOCI-9F | AC110V (C) | NO · Lead wire 0.5 m (I) | 9 stations · common exhaust · PT thread | $371.69 | |
| 3V2MNOCI-10F | AC110V (C) | NO · Lead wire 0.5 m (I) | 10 stations · common exhaust · PT thread | $411.85 | |
| 3V2MNOCI-11F | AC110V (C) | NO · Lead wire 0.5 m (I) | 11 stations · common exhaust · PT thread | $452.05 | |
| 3V2MNOCI-12F | AC110V (C) | NO · Lead wire 0.5 m (I) | 12 stations · common exhaust · PT thread | $492.21 | |
| 3V2MNOCI-13F | AC110V (C) | NO · Lead wire 0.5 m (I) | 13 stations · common exhaust · PT thread | $532.41 | |
| 3V2MNOCI-14F | AC110V (C) | NO · Lead wire 0.5 m (I) | 14 stations · common exhaust · PT thread | $572.57 | |
| 3V2MNOCI-15F | AC110V (C) | NO · Lead wire 0.5 m (I) | 15 stations · common exhaust · PT thread | $612.77 | |
| 3V2MNOCI-16F | AC110V (C) | NO · Lead wire 0.5 m (I) | 16 stations · common exhaust · PT thread | $652.93 | |
| 3V2MNOCI-17F | AC110V (C) | NO · Lead wire 0.5 m (I) | 17 stations · common exhaust · PT thread | $693.14 | |
| 3V2MNOCI-18F | AC110V (C) | NO · Lead wire 0.5 m (I) | 18 stations · common exhaust · PT thread | $733.29 | |
| 3V2MNOCI-19F | AC110V (C) | NO · Lead wire 0.5 m (I) | 19 stations · common exhaust · PT thread | $773.50 | |
| 3V2MNOCI-20F | AC110V (C) | NO · Lead wire 0.5 m (I) | 20 stations · common exhaust · PT thread | $813.65 | |
| 3V2MNCE-1F | AC24V (E) | NC · DIN connector | 1 station · common exhaust · PT thread | $50.24 | |
| 3V2MNCE-2F | AC24V (E) | NC · DIN connector | 2 stations · common exhaust · PT thread | $90.40 | |
| 3V2MNCE-3F | AC24V (E) | NC · DIN connector | 3 stations · common exhaust · PT thread | $130.60 | |
| 3V2MNCE-4F | AC24V (E) | NC · DIN connector | 4 stations · common exhaust · PT thread | $170.76 | |
| 3V2MNCE-5F | AC24V (E) | NC · DIN connector | 5 stations · common exhaust · PT thread | $210.97 | |
| 3V2MNCE-6F | AC24V (E) | NC · DIN connector | 6 stations · common exhaust · PT thread | $251.12 | |
| 3V2MNCE-7F | AC24V (E) | NC · DIN connector | 7 stations · common exhaust · PT thread | $291.33 | |
| 3V2MNCE-8F | AC24V (E) | NC · DIN connector | 8 stations · common exhaust · PT thread | $331.48 | |
| 3V2MNCE-9F | AC24V (E) | NC · DIN connector | 9 stations · common exhaust · PT thread | $371.69 | |
| 3V2MNCE-10F | AC24V (E) | NC · DIN connector | 10 stations · common exhaust · PT thread | $411.85 | |
| 3V2MNCE-11F | AC24V (E) | NC · DIN connector | 11 stations · common exhaust · PT thread | $452.05 | |
| 3V2MNCE-12F | AC24V (E) | NC · DIN connector | 12 stations · common exhaust · PT thread | $492.21 | |
| 3V2MNCE-13F | AC24V (E) | NC · DIN connector | 13 stations · common exhaust · PT thread | $532.41 | |
| 3V2MNCE-14F | AC24V (E) | NC · DIN connector | 14 stations · common exhaust · PT thread | $572.57 | |
| 3V2MNCE-15F | AC24V (E) | NC · DIN connector | 15 stations · common exhaust · PT thread | $612.77 | |
| 3V2MNCE-16F | AC24V (E) | NC · DIN connector | 16 stations · common exhaust · PT thread | $652.93 | |
| 3V2MNCE-17F | AC24V (E) | NC · DIN connector | 17 stations · common exhaust · PT thread | $693.14 | |
| 3V2MNCE-18F | AC24V (E) | NC · DIN connector | 18 stations · common exhaust · PT thread | $733.29 | |
| 3V2MNCE-19F | AC24V (E) | NC · DIN connector | 19 stations · common exhaust · PT thread | $773.50 | |
| 3V2MNCE-20F | AC24V (E) | NC · DIN connector | 20 stations · common exhaust · PT thread | $813.65 | |
| 3V2MNCEI-1F | AC24V (E) | NC · Lead wire 0.5 m (I) | 1 station · common exhaust · PT thread | $50.24 | |
| 3V2MNCEI-2F | AC24V (E) | NC · Lead wire 0.5 m (I) | 2 stations · common exhaust · PT thread | $90.40 | |
| 3V2MNCEI-3F | AC24V (E) | NC · Lead wire 0.5 m (I) | 3 stations · common exhaust · PT thread | $130.60 | |
| 3V2MNCEI-4F | AC24V (E) | NC · Lead wire 0.5 m (I) | 4 stations · common exhaust · PT thread | $170.76 | |
| 3V2MNCEI-5F | AC24V (E) | NC · Lead wire 0.5 m (I) | 5 stations · common exhaust · PT thread | $210.97 | |
| 3V2MNCEI-6F | AC24V (E) | NC · Lead wire 0.5 m (I) | 6 stations · common exhaust · PT thread | $251.12 | |
| 3V2MNCEI-7F | AC24V (E) | NC · Lead wire 0.5 m (I) | 7 stations · common exhaust · PT thread | $291.33 | |
| 3V2MNCEI-8F | AC24V (E) | NC · Lead wire 0.5 m (I) | 8 stations · common exhaust · PT thread | $331.48 | |
| 3V2MNCEI-9F | AC24V (E) | NC · Lead wire 0.5 m (I) | 9 stations · common exhaust · PT thread | $371.69 | |
| 3V2MNCEI-10F | AC24V (E) | NC · Lead wire 0.5 m (I) | 10 stations · common exhaust · PT thread | $411.85 | |
| 3V2MNCEI-11F | AC24V (E) | NC · Lead wire 0.5 m (I) | 11 stations · common exhaust · PT thread | $452.05 | |
| 3V2MNCEI-12F | AC24V (E) | NC · Lead wire 0.5 m (I) | 12 stations · common exhaust · PT thread | $492.21 | |
| 3V2MNCEI-13F | AC24V (E) | NC · Lead wire 0.5 m (I) | 13 stations · common exhaust · PT thread | $532.41 | |
| 3V2MNCEI-14F | AC24V (E) | NC · Lead wire 0.5 m (I) | 14 stations · common exhaust · PT thread | $572.57 | |
| 3V2MNCEI-15F | AC24V (E) | NC · Lead wire 0.5 m (I) | 15 stations · common exhaust · PT thread | $612.77 | |
| 3V2MNCEI-16F | AC24V (E) | NC · Lead wire 0.5 m (I) | 16 stations · common exhaust · PT thread | $652.93 | |
| 3V2MNCEI-17F | AC24V (E) | NC · Lead wire 0.5 m (I) | 17 stations · common exhaust · PT thread | $693.14 | |
| 3V2MNCEI-18F | AC24V (E) | NC · Lead wire 0.5 m (I) | 18 stations · common exhaust · PT thread | $733.29 | |
| 3V2MNCEI-19F | AC24V (E) | NC · Lead wire 0.5 m (I) | 19 stations · common exhaust · PT thread | $773.50 | |
| 3V2MNCEI-20F | AC24V (E) | NC · Lead wire 0.5 m (I) | 20 stations · common exhaust · PT thread | $813.65 | |
| 3V2MNOE-1F | AC24V (E) | NO · DIN connector | 1 station · common exhaust · PT thread | $50.24 | |
| 3V2MNOE-2F | AC24V (E) | NO · DIN connector | 2 stations · common exhaust · PT thread | $90.40 | |
| 3V2MNOE-3F | AC24V (E) | NO · DIN connector | 3 stations · common exhaust · PT thread | $130.60 | |
| 3V2MNOE-4F | AC24V (E) | NO · DIN connector | 4 stations · common exhaust · PT thread | $170.76 | |
| 3V2MNOE-5F | AC24V (E) | NO · DIN connector | 5 stations · common exhaust · PT thread | $210.97 | |
| 3V2MNOE-6F | AC24V (E) | NO · DIN connector | 6 stations · common exhaust · PT thread | $251.12 | |
| 3V2MNOE-7F | AC24V (E) | NO · DIN connector | 7 stations · common exhaust · PT thread | $291.33 | |
| 3V2MNOE-8F | AC24V (E) | NO · DIN connector | 8 stations · common exhaust · PT thread | $331.48 | |
| 3V2MNOE-9F | AC24V (E) | NO · DIN connector | 9 stations · common exhaust · PT thread | $371.69 | |
| 3V2MNOE-10F | AC24V (E) | NO · DIN connector | 10 stations · common exhaust · PT thread | $411.85 | |
| 3V2MNOE-11F | AC24V (E) | NO · DIN connector | 11 stations · common exhaust · PT thread | $452.05 | |
| 3V2MNOE-12F | AC24V (E) | NO · DIN connector | 12 stations · common exhaust · PT thread | $492.21 | |
| 3V2MNOE-13F | AC24V (E) | NO · DIN connector | 13 stations · common exhaust · PT thread | $532.41 | |
| 3V2MNOE-14F | AC24V (E) | NO · DIN connector | 14 stations · common exhaust · PT thread | $572.57 | |
| 3V2MNOE-15F | AC24V (E) | NO · DIN connector | 15 stations · common exhaust · PT thread | $612.77 | |
| 3V2MNOE-16F | AC24V (E) | NO · DIN connector | 16 stations · common exhaust · PT thread | $652.93 | |
| 3V2MNOE-17F | AC24V (E) | NO · DIN connector | 17 stations · common exhaust · PT thread | $693.14 | |
| 3V2MNOE-18F | AC24V (E) | NO · DIN connector | 18 stations · common exhaust · PT thread | $733.29 | |
| 3V2MNOE-19F | AC24V (E) | NO · DIN connector | 19 stations · common exhaust · PT thread | $773.50 | |
| 3V2MNOE-20F | AC24V (E) | NO · DIN connector | 20 stations · common exhaust · PT thread | $813.65 | |
| 3V2MNOEI-1F | AC24V (E) | NO · Lead wire 0.5 m (I) | 1 station · common exhaust · PT thread | $50.24 | |
| 3V2MNOEI-2F | AC24V (E) | NO · Lead wire 0.5 m (I) | 2 stations · common exhaust · PT thread | $90.40 | |
| 3V2MNOEI-3F | AC24V (E) | NO · Lead wire 0.5 m (I) | 3 stations · common exhaust · PT thread | $130.60 | |
| 3V2MNOEI-4F | AC24V (E) | NO · Lead wire 0.5 m (I) | 4 stations · common exhaust · PT thread | $170.76 | |
| 3V2MNOEI-5F | AC24V (E) | NO · Lead wire 0.5 m (I) | 5 stations · common exhaust · PT thread | $210.97 | |
| 3V2MNOEI-6F | AC24V (E) | NO · Lead wire 0.5 m (I) | 6 stations · common exhaust · PT thread | $251.12 | |
| 3V2MNOEI-7F | AC24V (E) | NO · Lead wire 0.5 m (I) | 7 stations · common exhaust · PT thread | $291.33 | |
| 3V2MNOEI-8F | AC24V (E) | NO · Lead wire 0.5 m (I) | 8 stations · common exhaust · PT thread | $331.48 | |
| 3V2MNOEI-9F | AC24V (E) | NO · Lead wire 0.5 m (I) | 9 stations · common exhaust · PT thread | $371.69 | |
| 3V2MNOEI-10F | AC24V (E) | NO · Lead wire 0.5 m (I) | 10 stations · common exhaust · PT thread | $411.85 | |
| 3V2MNOEI-11F | AC24V (E) | NO · Lead wire 0.5 m (I) | 11 stations · common exhaust · PT thread | $452.05 | |
| 3V2MNOEI-12F | AC24V (E) | NO · Lead wire 0.5 m (I) | 12 stations · common exhaust · PT thread | $492.21 | |
| 3V2MNOEI-13F | AC24V (E) | NO · Lead wire 0.5 m (I) | 13 stations · common exhaust · PT thread | $532.41 | |
| 3V2MNOEI-14F | AC24V (E) | NO · Lead wire 0.5 m (I) | 14 stations · common exhaust · PT thread | $572.57 | |
| 3V2MNOEI-15F | AC24V (E) | NO · Lead wire 0.5 m (I) | 15 stations · common exhaust · PT thread | $612.77 | |
| 3V2MNOEI-16F | AC24V (E) | NO · Lead wire 0.5 m (I) | 16 stations · common exhaust · PT thread | $652.93 | |
| 3V2MNOEI-17F | AC24V (E) | NO · Lead wire 0.5 m (I) | 17 stations · common exhaust · PT thread | $693.14 | |
| 3V2MNOEI-18F | AC24V (E) | NO · Lead wire 0.5 m (I) | 18 stations · common exhaust · PT thread | $733.29 | |
| 3V2MNOEI-19F | AC24V (E) | NO · Lead wire 0.5 m (I) | 19 stations · common exhaust · PT thread | $773.50 | |
| 3V2MNOEI-20F | AC24V (E) | NO · Lead wire 0.5 m (I) | 20 stations · common exhaust · PT thread | $813.65 | |
| 3V2MNCF-1F | DC12V (F) | NC · DIN connector | 1 station · common exhaust · PT thread | $50.24 | |
| 3V2MNCF-2F | DC12V (F) | NC · DIN connector | 2 stations · common exhaust · PT thread | $90.40 | |
| 3V2MNCF-3F | DC12V (F) | NC · DIN connector | 3 stations · common exhaust · PT thread | $130.60 | |
| 3V2MNCF-4F | DC12V (F) | NC · DIN connector | 4 stations · common exhaust · PT thread | $170.76 | |
| 3V2MNCF-5F | DC12V (F) | NC · DIN connector | 5 stations · common exhaust · PT thread | $210.97 | |
| 3V2MNCF-6F | DC12V (F) | NC · DIN connector | 6 stations · common exhaust · PT thread | $251.12 | |
| 3V2MNCF-7F | DC12V (F) | NC · DIN connector | 7 stations · common exhaust · PT thread | $291.33 | |
| 3V2MNCF-8F | DC12V (F) | NC · DIN connector | 8 stations · common exhaust · PT thread | $331.48 | |
| 3V2MNCF-9F | DC12V (F) | NC · DIN connector | 9 stations · common exhaust · PT thread | $371.69 | |
| 3V2MNCF-10F | DC12V (F) | NC · DIN connector | 10 stations · common exhaust · PT thread | $411.85 | |
| 3V2MNCF-11F | DC12V (F) | NC · DIN connector | 11 stations · common exhaust · PT thread | $452.05 | |
| 3V2MNCF-12F | DC12V (F) | NC · DIN connector | 12 stations · common exhaust · PT thread | $492.21 | |
| 3V2MNCF-13F | DC12V (F) | NC · DIN connector | 13 stations · common exhaust · PT thread | $532.41 | |
| 3V2MNCF-14F | DC12V (F) | NC · DIN connector | 14 stations · common exhaust · PT thread | $572.57 | |
| 3V2MNCF-15F | DC12V (F) | NC · DIN connector | 15 stations · common exhaust · PT thread | $612.77 | |
| 3V2MNCF-16F | DC12V (F) | NC · DIN connector | 16 stations · common exhaust · PT thread | $652.93 | |
| 3V2MNCF-17F | DC12V (F) | NC · DIN connector | 17 stations · common exhaust · PT thread | $693.14 | |
| 3V2MNCF-18F | DC12V (F) | NC · DIN connector | 18 stations · common exhaust · PT thread | $733.29 | |
| 3V2MNCF-19F | DC12V (F) | NC · DIN connector | 19 stations · common exhaust · PT thread | $773.50 | |
| 3V2MNCF-20F | DC12V (F) | NC · DIN connector | 20 stations · common exhaust · PT thread | $813.65 | |
| 3V2MNCFI-1F | DC12V (F) | NC · Lead wire 0.5 m (I) | 1 station · common exhaust · PT thread | $50.24 | |
| 3V2MNCFI-2F | DC12V (F) | NC · Lead wire 0.5 m (I) | 2 stations · common exhaust · PT thread | $90.40 | |
| 3V2MNCFI-3F | DC12V (F) | NC · Lead wire 0.5 m (I) | 3 stations · common exhaust · PT thread | $130.60 | |
| 3V2MNCFI-4F | DC12V (F) | NC · Lead wire 0.5 m (I) | 4 stations · common exhaust · PT thread | $170.76 | |
| 3V2MNCFI-5F | DC12V (F) | NC · Lead wire 0.5 m (I) | 5 stations · common exhaust · PT thread | $210.97 | |
| 3V2MNCFI-6F | DC12V (F) | NC · Lead wire 0.5 m (I) | 6 stations · common exhaust · PT thread | $251.12 | |
| 3V2MNCFI-7F | DC12V (F) | NC · Lead wire 0.5 m (I) | 7 stations · common exhaust · PT thread | $291.33 | |
| 3V2MNCFI-8F | DC12V (F) | NC · Lead wire 0.5 m (I) | 8 stations · common exhaust · PT thread | $331.48 | |
| 3V2MNCFI-9F | DC12V (F) | NC · Lead wire 0.5 m (I) | 9 stations · common exhaust · PT thread | $371.69 | |
| 3V2MNCFI-10F | DC12V (F) | NC · Lead wire 0.5 m (I) | 10 stations · common exhaust · PT thread | $411.85 | |
| 3V2MNCFI-11F | DC12V (F) | NC · Lead wire 0.5 m (I) | 11 stations · common exhaust · PT thread | $452.05 | |
| 3V2MNCFI-12F | DC12V (F) | NC · Lead wire 0.5 m (I) | 12 stations · common exhaust · PT thread | $492.21 | |
| 3V2MNCFI-13F | DC12V (F) | NC · Lead wire 0.5 m (I) | 13 stations · common exhaust · PT thread | $532.41 | |
| 3V2MNCFI-14F | DC12V (F) | NC · Lead wire 0.5 m (I) | 14 stations · common exhaust · PT thread | $572.57 | |
| 3V2MNCFI-15F | DC12V (F) | NC · Lead wire 0.5 m (I) | 15 stations · common exhaust · PT thread | $612.77 | |
| 3V2MNCFI-16F | DC12V (F) | NC · Lead wire 0.5 m (I) | 16 stations · common exhaust · PT thread | $652.93 | |
| 3V2MNCFI-17F | DC12V (F) | NC · Lead wire 0.5 m (I) | 17 stations · common exhaust · PT thread | $693.14 | |
| 3V2MNCFI-18F | DC12V (F) | NC · Lead wire 0.5 m (I) | 18 stations · common exhaust · PT thread | $733.29 | |
| 3V2MNCFI-19F | DC12V (F) | NC · Lead wire 0.5 m (I) | 19 stations · common exhaust · PT thread | $773.50 | |
| 3V2MNCFI-20F | DC12V (F) | NC · Lead wire 0.5 m (I) | 20 stations · common exhaust · PT thread | $813.65 | |
| 3V2MNOF-1F | DC12V (F) | NO · DIN connector | 1 station · common exhaust · PT thread | $50.24 | |
| 3V2MNOF-2F | DC12V (F) | NO · DIN connector | 2 stations · common exhaust · PT thread | $90.40 | |
| 3V2MNOF-3F | DC12V (F) | NO · DIN connector | 3 stations · common exhaust · PT thread | $130.60 | |
| 3V2MNOF-4F | DC12V (F) | NO · DIN connector | 4 stations · common exhaust · PT thread | $170.76 | |
| 3V2MNOF-5F | DC12V (F) | NO · DIN connector | 5 stations · common exhaust · PT thread | $210.97 | |
| 3V2MNOF-6F | DC12V (F) | NO · DIN connector | 6 stations · common exhaust · PT thread | $251.12 | |
| 3V2MNOF-7F | DC12V (F) | NO · DIN connector | 7 stations · common exhaust · PT thread | $291.33 | |
| 3V2MNOF-8F | DC12V (F) | NO · DIN connector | 8 stations · common exhaust · PT thread | $331.48 | |
| 3V2MNOF-9F | DC12V (F) | NO · DIN connector | 9 stations · common exhaust · PT thread | $371.69 | |
| 3V2MNOF-10F | DC12V (F) | NO · DIN connector | 10 stations · common exhaust · PT thread | $411.85 | |
| 3V2MNOF-11F | DC12V (F) | NO · DIN connector | 11 stations · common exhaust · PT thread | $452.05 | |
| 3V2MNOF-12F | DC12V (F) | NO · DIN connector | 12 stations · common exhaust · PT thread | $492.21 | |
| 3V2MNOF-13F | DC12V (F) | NO · DIN connector | 13 stations · common exhaust · PT thread | $532.41 | |
| 3V2MNOF-14F | DC12V (F) | NO · DIN connector | 14 stations · common exhaust · PT thread | $572.57 | |
| 3V2MNOF-15F | DC12V (F) | NO · DIN connector | 15 stations · common exhaust · PT thread | $612.77 | |
| 3V2MNOF-16F | DC12V (F) | NO · DIN connector | 16 stations · common exhaust · PT thread | $652.93 | |
| 3V2MNOF-17F | DC12V (F) | NO · DIN connector | 17 stations · common exhaust · PT thread | $693.14 | |
| 3V2MNOF-18F | DC12V (F) | NO · DIN connector | 18 stations · common exhaust · PT thread | $733.29 | |
| 3V2MNOF-19F | DC12V (F) | NO · DIN connector | 19 stations · common exhaust · PT thread | $773.50 | |
| 3V2MNOF-20F | DC12V (F) | NO · DIN connector | 20 stations · common exhaust · PT thread | $813.65 | |
| 3V2MNOFI-1F | DC12V (F) | NO · Lead wire 0.5 m (I) | 1 station · common exhaust · PT thread | $50.24 | |
| 3V2MNOFI-2F | DC12V (F) | NO · Lead wire 0.5 m (I) | 2 stations · common exhaust · PT thread | $90.40 | |
| 3V2MNOFI-3F | DC12V (F) | NO · Lead wire 0.5 m (I) | 3 stations · common exhaust · PT thread | $130.60 | |
| 3V2MNOFI-4F | DC12V (F) | NO · Lead wire 0.5 m (I) | 4 stations · common exhaust · PT thread | $170.76 | |
| 3V2MNOFI-5F | DC12V (F) | NO · Lead wire 0.5 m (I) | 5 stations · common exhaust · PT thread | $210.97 | |
| 3V2MNOFI-6F | DC12V (F) | NO · Lead wire 0.5 m (I) | 6 stations · common exhaust · PT thread | $251.12 | |
| 3V2MNOFI-7F | DC12V (F) | NO · Lead wire 0.5 m (I) | 7 stations · common exhaust · PT thread | $291.33 | |
| 3V2MNOFI-8F | DC12V (F) | NO · Lead wire 0.5 m (I) | 8 stations · common exhaust · PT thread | $331.48 | |
| 3V2MNOFI-9F | DC12V (F) | NO · Lead wire 0.5 m (I) | 9 stations · common exhaust · PT thread | $371.69 | |
| 3V2MNOFI-10F | DC12V (F) | NO · Lead wire 0.5 m (I) | 10 stations · common exhaust · PT thread | $411.85 | |
| 3V2MNOFI-11F | DC12V (F) | NO · Lead wire 0.5 m (I) | 11 stations · common exhaust · PT thread | $452.05 | |
| 3V2MNOFI-12F | DC12V (F) | NO · Lead wire 0.5 m (I) | 12 stations · common exhaust · PT thread | $492.21 | |
| 3V2MNOFI-13F | DC12V (F) | NO · Lead wire 0.5 m (I) | 13 stations · common exhaust · PT thread | $532.41 | |
| 3V2MNOFI-14F | DC12V (F) | NO · Lead wire 0.5 m (I) | 14 stations · common exhaust · PT thread | $572.57 | |
| 3V2MNOFI-15F | DC12V (F) | NO · Lead wire 0.5 m (I) | 15 stations · common exhaust · PT thread | $612.77 | |
| 3V2MNOFI-16F | DC12V (F) | NO · Lead wire 0.5 m (I) | 16 stations · common exhaust · PT thread | $652.93 | |
| 3V2MNOFI-17F | DC12V (F) | NO · Lead wire 0.5 m (I) | 17 stations · common exhaust · PT thread | $693.14 | |
| 3V2MNOFI-18F | DC12V (F) | NO · Lead wire 0.5 m (I) | 18 stations · common exhaust · PT thread | $733.29 | |
| 3V2MNOFI-19F | DC12V (F) | NO · Lead wire 0.5 m (I) | 19 stations · common exhaust · PT thread | $773.50 | |
| 3V2MNOFI-20F | DC12V (F) | NO · Lead wire 0.5 m (I) | 20 stations · common exhaust · PT thread | $813.65 |
Need a combination that is not listed? Request a quote.
Where the 3V2M Is Used
Single-acting cylinders
A 3/2-way valve supplies and exhausts one port, the usual way to drive a spring-return cylinder.
Air blow and pilot signals
Switches compressed air on and off for blow-off nozzles or as a pilot signal to larger valves.
Multi-valve panels
Several valves on one supply and one wiring run save space in the cabinet.
Choosing the Right 3V2M Configuration
Choose the valve type: normally closed (NC) keeps the outlet shut until the coil is energised; normally open (NO) passes air until it is energised.
Choose the coil voltage to match your control circuit: DC24V (B), AC220V (A), AC110V (C), AC24V (E), DC12V (F). Supply tolerance is AC ±15% and DC ±10%.
For the electrical entry, the standard DIN connector takes your own cable; the I version has a 0.5 m lead wire already attached.
Then the number of stations (1F to 20F) and the exhaust: common, or individual (D) for each station. The thread is PT unless marked G or T.
AirTAC 3V2M FAQ
Both are stocked: NC opens the outlet when energised, NO closes it when energised.
DC24V (B), AC220V (A), AC110V (C), AC24V (E), DC12V (F). The letter after the port size or valve type gives the voltage.
0 to 0.8 MPa (0-114 psi), proof pressure 1.2 MPa, -20 to +70 °C, on air filtered to 40 µm. No lubrication is needed.
Common exhaust collects all stations into one outlet; individual exhaust (D) gives each station its own exhaust.
No. You can order a single piece. Orders are processed and handed to the carrier within 3-5 business days.
Buying the 3V2M from AirtacDistr
Genuine AirTAC parts
Every order code on this page is the AirTAC factory part number. Specifications follow the AirTAC Products Catalog 2026A. About us
Ready in 3-5 business days
That is our time to process the order and hand it to the carrier. No minimum order: a single piece can be ordered.
14-day returns, 1-year warranty
Return within 14 days of delivery; the buyer pays return shipping. The warranty covers defects not caused by misuse. Return policy
Engineering help
Send your application details and we will confirm the right order code, usually within 7-8 hours. Ask us
Page data checked against the live catalog on 2026-10-30.
Request a Quote for the 3V2M
Send the order code, quantity and destination. We confirm price, stock and lead time, usually within 7-8 hours.
Thank you. We received your request for 3V2MNCB-1F and will confirm price, stock and lead time — usually within 7-8 hours.
