Airtac 3V2M Solenoid Valve 3V2MNCA-2F
The AirTAC Airtac 3V2M Solenoid Valve 3V2MNCA-2F is a genuine 3-port 2-position (3/2) solenoid valve with 1/8 in ports. It either feeds its outlet or vents it to exhaust, which is what makes it the valve for single-acting cylinders, on/off air blow, clamping, vacuum switching and pilot duty.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally closed
- Port size1/8 in
- Coil voltageAC220V
- Electrical entryDIN plug (DIN socket type)
- Stations2
- Flow (Cv)0.1
- Series3V2M
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 3V2M Solenoid Valve 3V2MNCA-2F
Two 3/2 NC valve bodies on one 2F base: that is the whole idea behind the 3V2MNCA-2F. Both direct-acting, spring-return poppet valves draw air from a single PT1/8 supply port and share one wiring strip for their AC220V coils.
The diagnostic payoff is real on a two-station machine: if a function drops out, you check one air inlet and one wiring point instead of tracing two separate installations. Each coil is 7 VA (14 VA total), the DIN plugs carry an IP65 rating, and the manual override on each body lets you jog either station by hand during setup. Both stations sit closed until energised - an NC behaviour fixed at manufacture, with no field conversion possible.
Airtac 3V2M Solenoid Valve 3V2MNCA-2F Technical Specifications
| Model | Airtac 3V2M Solenoid Valve 3V2MNCA-2F |
|---|---|
| Series | 3V2M |
| Valve type | 3/2-way (3-port, 2-position) |
| Function | Direct-acting, single solenoid, spring return |
| Initial state | Normally closed |
| Item form | Complete assembly — 2 valves on a shared base |
| Exhaust | Centralised exhaust |
| Port size | 1/8 in |
| Thread | PT |
| Coil voltage | AC220V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | 7 VA |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
| Vacuum service | Not rated for vacuum |
| Flow coefficient | Cv 0.1 |
| Temperature | -20 to 70 C |
| Construction | Coaxial shut-off (poppet), base-mounted, spring return |
| Protection | IP65 (DIN 40050) |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V2M catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V2M Solenoid Valve 3V2MNCA-2F
| 3V2M | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NC | Normally closed: no air at the outlet until the coil is energised. |
| AC220V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| 2F | 2 stations in one assembly, centralised exhaust. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V2M Solenoid Valve 3V2MNCA-2F Is Used
Lathe chuck and tailstock
A spring-return chuck clamp and a tailstock pusher on a small lathe each get their own NC valve while sharing one air drop and one wiring point.
Sorting gate diverter pair
Two diverters at a conveyor junction switch packages independently, yet the shared manifold keeps the pneumatic plumbing to a single supply line.
Leak-test fixture
One valve clamps the part, the second vents the test circuit - a two-station sequence the 2F base handles from one consolidated supply.
Is the Airtac 3V2M Solenoid Valve 3V2MNCA-2F the Right Part?
Two stations through a base still costs flow: Cv 0.1 per path versus Cv 0.18 on an individually ported 3V2 (vacuum rated) and Cv 0.62 on the 3V3 at 1/4 in (also vacuum rated). Choose the standalone valves if a station needs that extra flow; pick 3V1 at 3.0 W DC where power draw is the constraint. For double-acting cylinders you need the 5-port AirTAC 4V series instead of any 3/2 valve.
Match five points to your machine before ordering: NC initial state (unchangeable afterwards), AC220V coil, DIN plug entry, 2F station count, centralised exhaust. PT is the thread this family ships with as standard, and G or NPT can be specified at order time.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V2M Solenoid Valve 3V2MNCA-2F FAQ
Two-station 3/2 NC assembly, PT1/8 ports, Cv 0.1 per path, operating pressure 0-0.8 MPa, temperature range -20 to 70 C, each AC220V coil 7 VA (14 VA combined), IP65 to DIN 40050, clean dry air filtered to 40 um or finer.
Each station feeds or vents a single-acting spring-return cylinder, an on/off blow line, a clamp or a pilot signal - three ports, two states per valve. It cannot drive a double-acting cylinder, which needs pressurisation on both sides; for that specify the AirTAC 4V 5-port series. Response time, weight and dimensions are not stated for this family, so confirm them from the datasheet via RFQ.
