Airtac 3V2M Solenoid Valve 3V2MNCA-11F
The AirTAC Airtac 3V2M Solenoid Valve 3V2MNCA-11F is a genuine 3-port 2-position (3/2) solenoid valve with 1/8 in ports. It either feeds its outlet or vents it to exhaust, which is what makes it the valve for single-acting cylinders, on/off air blow, clamping, vacuum switching and pilot duty.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally closed
- Port size1/8 in
- Coil voltageAC220V
- Electrical entryDIN plug (DIN socket type)
- Stations11
- Flow (Cv)0.1
- Series3V2M
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 3V2M Solenoid Valve 3V2MNCA-11F
Ordering code 3V2MNCA-11F buys an eleven-station 3/2 manifold in one line item: eleven normally closed poppet valves with AC220V coils and DIN plug entry, seated on an 11-station base with a centralised exhaust. The 3V2M system allows mixed valve counts and types on one base, but this code keeps every station identical, which simplifies spares holding.
Because all eleven valves share one air supply and one wiring loom, a fault shows up against a common reference and fault-finding is quicker than tracing eleven individual valves and their fittings. Each IP65 coil draws 7 VA, so a fully energised assembly needs about 77 VA from the control transformer, and the manual override on every body speeds up commissioning.
Airtac 3V2M Solenoid Valve 3V2MNCA-11F Technical Specifications
| Model | Airtac 3V2M Solenoid Valve 3V2MNCA-11F |
|---|---|
| Series | 3V2M |
| Valve type | 3/2-way (3-port, 2-position) |
| Function | Direct-acting, single solenoid, spring return |
| Initial state | Normally closed |
| Item form | Complete assembly — 11 valves on a shared base |
| Exhaust | Centralised exhaust |
| Port size | 1/8 in |
| Thread | PT |
| Coil voltage | AC220V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | 7 VA |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
| Vacuum service | Not rated for vacuum |
| Flow coefficient | Cv 0.1 |
| Temperature | -20 to 70 C |
| Construction | Coaxial shut-off (poppet), base-mounted, spring return |
| Protection | IP65 (DIN 40050) |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V2M catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V2M Solenoid Valve 3V2MNCA-11F
| 3V2M | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NC | Normally closed: no air at the outlet until the coil is energised. |
| AC220V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| 11F | 11 stations in one assembly, centralised exhaust. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V2M Solenoid Valve 3V2MNCA-11F Is Used
Palletiser gripper bank
Switch the pneumatic grippers of a multi-arm palletising cell, one NC valve per jaw set on the shared base.
Filling line heads
Control the fill-head clamps on an eleven-head bottling carousel, with every coil wired from one common run.
High-cycle pin ejectors
Cycle the ejection pins of a stamping die, one 3/2 valve per pin with spring return inside the tool.
Is the Airtac 3V2M Solenoid Valve 3V2MNCA-11F the Right Part?
Specify this 11-station assembly by five points: NC initial state (fixed at manufacture; the gasket cannot be flipped to change it), AC220V coil, DIN plug entry, PT thread (G and NPT available to order) and centralised exhaust. Flow is Cv 0.1 per station because the path runs through the base; where a single circuit needs more, split it off to an individual 3V2 (Cv 0.18 at 1/8 in, 0.19 at 1/4 in, vacuum-rated) or 3V3 (Cv 0.62, 1/4 in, vacuum-rated). 3V1 at 3.0 W DC suits small, low-power duties. For double-acting cylinders, move to the AirTAC 4V series.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V2M Solenoid Valve 3V2MNCA-11F FAQ
Each of the eleven stations is a 3/2 direct-acting spring-return poppet valve with Cv 0.1, PT1/8 ports, 0-0.8 MPa (0-114 psi) operating pressure, -20 to 70 C temperature, a 7 VA AC220V coil and IP65 (DIN 40050) protection, with the medium filtered to 40 um or finer.
No. NC is built into each valve and its dedicated base gasket; reversing the gasket will not change the state and there is no field conversion. If any station must pass air while de-energised, order that station's valve as NO at the time of purchase.
