Airtac 3V2M Solenoid Valve 3V2MNCAI-13F
The AirTAC Airtac 3V2M Solenoid Valve 3V2MNCAI-13F is a genuine 3-port 2-position (3/2) solenoid valve with 1/8 in ports. It either feeds its outlet or vents it to exhaust, which is what makes it the valve for single-acting cylinders, on/off air blow, clamping, vacuum switching and pilot duty.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally closed
- Port size1/8 in
- Coil voltageAC220V
- Electrical entryFlying lead (lead-out wire type)
- Stations13
- Flow (Cv)0.1
- Series3V2M
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 3V2M Solenoid Valve 3V2MNCAI-13F
Thirteen stations, one base, one pair of common connections: the 3V2MNCAI-13F is a complete AC220V valve group with flying-lead coils and NC outlets that stay closed until each coil is energised. The direct-acting, spring-return, coaxial shut-off construction keeps sealing positive at every position even when only part of the bank is working.
Plan the electrics around the coil count: each station draws 7 VA, so a fully energised 13-station bank presents roughly 91 VA to the AC220V supply - size the transformer and fusing for that worst case, not for a single valve. Centralised exhaust sends all thirteen vents to one port, and a manual override on every body lets you jog a station during commissioning.
Airtac 3V2M Solenoid Valve 3V2MNCAI-13F Technical Specifications
| Model | Airtac 3V2M Solenoid Valve 3V2MNCAI-13F |
|---|---|
| Series | 3V2M |
| Valve type | 3/2-way (3-port, 2-position) |
| Function | Direct-acting, single solenoid, spring return |
| Initial state | Normally closed |
| Item form | Complete assembly — 13 valves on a shared base |
| Exhaust | Centralised exhaust |
| Port size | 1/8 in |
| Thread | PT |
| Coil voltage | AC220V |
|---|---|
| Electrical entry | Flying lead (lead-out wire type) |
| Coil power | 7 VA |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
| Vacuum service | Not rated for vacuum |
| Flow coefficient | Cv 0.1 |
| Temperature | -20 to 70 C |
| Construction | Coaxial shut-off (poppet), base-mounted, spring return |
| Protection | IP65 (DIN 40050) |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V2M catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V2M Solenoid Valve 3V2MNCAI-13F
| 3V2M | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NC | Normally closed: no air at the outlet until the coil is energised. |
| AC220V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| I | Electrical entry: I = flying lead, otherwise a DIN plug. |
| 13F | 13 stations in one assembly, centralised exhaust. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V2M Solenoid Valve 3V2MNCAI-13F Is Used
Carton erector clamps
Flap and case clamps on an erector release the moment power fails, because each NC valve vents its single-acting cylinder when de-energised.
Textile machine jet bank
Thirteen individual air jets on a winding machine are sequenced from one manifold, one supply line and one wiring loom.
Pilot stage for large process valves
Each 3/2 station pilots a bigger pneumatic actuator, with the manifold consolidating the pilot air supply and its wiring into one panel connection.
Is the Airtac 3V2M Solenoid Valve 3V2MNCAI-13F the Right Part?
Five points define this order: NC state, AC220V, flying-lead entry, thirteen stations, centralised exhaust, plus the PT thread (G and NPT are catalogue options). Fix the state before buying - a 3V2M NC valve stays NC for life; reversing the base gasket does not convert it, so order NO valves if outlets must pass air at rest.
Flow sizing runs the other way too: at Cv 0.1 per station the 3V2M family is about density, not volume. A standalone 3V2 (Cv 0.18 at 1/8 in, 0.19 at 1/4 in, vacuum-rated) or 3V3 (Cv 0.62, 1/4 in, vacuum-rated) covers positions that need more air, while 3V1 at 3.0 W DC is the low-power pick for light duties. For double-acting cylinders, move to the AirTAC 4V series.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V2M Solenoid Valve 3V2MNCAI-13F FAQ
Thirteen 3/2 NC direct-acting valves with spring return, each Cv 0.1 on a PT1/8 port, 0-0.8 MPa pressure range, -20 to 70 C media temperature, AC220V coils at 7 VA, IP65 to DIN 40050, flying-lead entry, centralised exhaust and a manual override per station. Air must be filtered to 40 um or finer; lubrication is not required.
The machined base in the 3V2MNCAI-13F has thirteen positions and cannot be extended; order a larger assembly such as the 3V2MNCAI-14F if the machine grows. Within a base, valve types mix freely, so NC and NO valves can share the same supply and wiring.
