Airtac 3V2M Solenoid Valve 3V2MNCA-17F
The AirTAC Airtac 3V2M Solenoid Valve 3V2MNCA-17F is a genuine 3-port 2-position (3/2) solenoid valve with 1/8 in ports. It either feeds its outlet or vents it to exhaust, which is what makes it the valve for single-acting cylinders, on/off air blow, clamping, vacuum switching and pilot duty.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally closed
- Port size1/8 in
- Coil voltageAC220V
- Electrical entryDIN plug (DIN socket type)
- Stations17
- Flow (Cv)0.1
- Series3V2M
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 3V2M Solenoid Valve 3V2MNCA-17F
The 3V2MNCA-17F puts seventeen NC 3/2 valve stations behind one air inlet and one electrical feed. Each valve is a direct-acting, spring-return poppet with an AC220V coil on a DIN plug, and the base exhausts centrally, so blown-off chips, dust or product leave through a single ducted point.
Seventeen stations is where the shared-wiring design earns its keep: one loom, one socket pattern, and a manual override on each body make commissioning and later troubleshooting methodical. Sealing is coaxial shut-off, coil power is 7 VA AC per station, and the assembly is rated IP65 (DIN 40050).
Airtac 3V2M Solenoid Valve 3V2MNCA-17F Technical Specifications
| Model | Airtac 3V2M Solenoid Valve 3V2MNCA-17F |
|---|---|
| Series | 3V2M |
| Valve type | 3/2-way (3-port, 2-position) |
| Function | Direct-acting, single solenoid, spring return |
| Initial state | Normally closed |
| Item form | Complete assembly — 17 valves on a shared base |
| Exhaust | Centralised exhaust |
| Port size | 1/8 in |
| Thread | PT |
| Coil voltage | AC220V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | 7 VA |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
| Vacuum service | Not rated for vacuum |
| Flow coefficient | Cv 0.1 |
| Temperature | -20 to 70 C |
| Construction | Coaxial shut-off (poppet), base-mounted, spring return |
| Protection | IP65 (DIN 40050) |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V2M catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V2M Solenoid Valve 3V2MNCA-17F
| 3V2M | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NC | Normally closed: no air at the outlet until the coil is energised. |
| AC220V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| 17F | 17 stations in one assembly, centralised exhaust. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V2M Solenoid Valve 3V2MNCA-17F Is Used
Press brake guard interlocks
Guard locks and hold-downs on a press brake stay released until the control energises the matching NC station.
Weld cell clamp bank
Weld fixtures clamp sheet with spring-return cylinders, each clamp on its own valve, exhausts ducted to one central point.
Machining centre chip blow-off
Chip and coolant blow nozzles around a machining centre pulse in sequence, all venting through the single central port.
Is the Airtac 3V2M Solenoid Valve 3V2MNCA-17F the Right Part?
Lock in the configuration first: normally closed state, AC220V coils, DIN plug entry, 17 stations with centralised exhaust, PT1/8 ports (G and NPT as catalogue options to order). Remember the state is fixed at order - flipping the dedicated base gasket does not convert NC to NO, and no field change can.
Size each station honestly: Cv 0.1 suits small single-acting cylinders, clamps and blow duties; anything thirstier belongs on an individual 3V2 (Cv 0.18 at 1/8 in, 0.19 at 1/4 in, vacuum-rated) or a 3V3 (Cv 0.62, 1/4 in). Keep 3V1 at 3.0 W DC for low-power tasks, and use the AirTAC 4V series for double-acting cylinders.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V2M Solenoid Valve 3V2MNCA-17F FAQ
Seventeen NC 3/2 stations, Cv 0.1 each, pressure 0-0.8 MPa (0-114 psi), temperature -20 to 70 C, 7 VA per AC220V coil (7.0 W on DC variants), IP65 (DIN 40050), centralised exhaust, PT1/8 thread.
NC is right when stations must be vented while de-energised, as on clamps and guards; NO passes air until energised. The choice is fixed at order time - reversing the dedicated base gasket does not convert the state, so all 17 stations must be specified correctly up front.
