Airtac 3V2M Solenoid Valve 3V2MNCAI-12F
The AirTAC Airtac 3V2M Solenoid Valve 3V2MNCAI-12F is a genuine 3-port 2-position (3/2) solenoid valve with 1/8 in ports. It either feeds its outlet or vents it to exhaust, which is what makes it the valve for single-acting cylinders, on/off air blow, clamping, vacuum switching and pilot duty.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally closed
- Port size1/8 in
- Coil voltageAC220V
- Electrical entryFlying lead (lead-out wire type)
- Stations12
- Flow (Cv)0.1
- Series3V2M
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 3V2M Solenoid Valve 3V2MNCAI-12F
The 3V2MNCAI-12F packs twelve NC 3/2 valves onto a single 3V2M base with a flying lead from every AC220V coil. Each position is direct-acting and spring-return, using a coaxial popet that either feeds its outlet or vents it - so a twelve-axis machine gets twelve independent on/off air circuits from one air connection and one wiring run.
Flow is the honest limit here: routing through the base holds each station to Cv 0.1, against 0.18 for an individually ported 3V2. Clamping, blowing and pilot duty sit comfortably in that envelope; fast-cycling cylinders may not. All twelve exhausts combine into one centralised port, which simplifies silencing and keeps panel pipework tidy. Every unit is genuine AirTAC, with RFQ support from AirtacDistr.
Airtac 3V2M Solenoid Valve 3V2MNCAI-12F Technical Specifications
| Model | Airtac 3V2M Solenoid Valve 3V2MNCAI-12F |
|---|---|
| Series | 3V2M |
| Valve type | 3/2-way (3-port, 2-position) |
| Function | Direct-acting, single solenoid, spring return |
| Initial state | Normally closed |
| Item form | Complete assembly — 12 valves on a shared base |
| Exhaust | Centralised exhaust |
| Port size | 1/8 in |
| Thread | PT |
| Coil voltage | AC220V |
|---|---|
| Electrical entry | Flying lead (lead-out wire type) |
| Coil power | 7 VA |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
| Vacuum service | Not rated for vacuum |
| Flow coefficient | Cv 0.1 |
| Temperature | -20 to 70 C |
| Construction | Coaxial shut-off (poppet), base-mounted, spring return |
| Protection | IP65 (DIN 40050) |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V2M catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V2M Solenoid Valve 3V2MNCAI-12F
| 3V2M | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NC | Normally closed: no air at the outlet until the coil is energised. |
| AC220V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| I | Electrical entry: I = flying lead, otherwise a DIN plug. |
| 12F | 12 stations in one assembly, centralised exhaust. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V2M Solenoid Valve 3V2MNCAI-12F Is Used
Belt stop and release stations
Twelve product-stop pins along a packaging conveyor each retract on power loss thanks to the NC state, keeping the line fail-safe between stops.
Machining fixture clamps
Swing clamps on a CNC fixture column stay retracted until energised, so a chuck-loaded part is never clamped by an uncommanded air pulse.
Sample vial handling in lab automation
Individual vial lifters and stoppers on an analyser deck switch one at a time from a single manifold supply and shared wiring.
Is the Airtac 3V2M Solenoid Valve 3V2MNCAI-12F the Right Part?
Match five points before ordering: NC initial state, AC220V coil, flying-lead entry, twelve stations, centralised exhaust - and remember the NC choice is permanent; the base gasket cannot be reversed to make it NO. PT1/8 thread is the family standard, with G and NPT available to order.
On sizing: 3V2M buys layout density at Cv 0.1 per station. Step up to a standalone 3V2 (Cv 0.18 at 1/8 in, 0.19 at 1/4 in) or the 3V3 (Cv 0.62, 1/4 in, vacuum-rated) for any position needing more flow, or down to 3V1 at 3.0 W DC where the duty is light and power is scarce. Double-acting cylinders need a 5-port valve - specify the AirTAC 4V series.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V2M Solenoid Valve 3V2MNCAI-12F FAQ
Per station: 3/2 NC, direct-acting, single solenoid, spring return, Cv 0.1, PT1/8 port, 0-0.8 MPa, -20 to 70 C, AC220V at 7 VA, IP65 (DIN 40050). Assembly: twelve stations, centralised exhaust, flying-lead entry, air filtered to 40 um or better, no lubrication needed.
A 3/2 valve has three ports and two states: it feeds the outlet or vents it. That suits single-acting spring-return cylinders, air blow nozzles, clamps and pilot stages - not double-acting cylinders, which need a 5-port valve such as the AirTAC 4V series.
