Airtac 3V2M Solenoid Valve 3V2MNCAI-14F
The AirTAC Airtac 3V2M Solenoid Valve 3V2MNCAI-14F is a genuine 3-port 2-position (3/2) solenoid valve with 1/8 in ports. It either feeds its outlet or vents it to exhaust, which is what makes it the valve for single-acting cylinders, on/off air blow, clamping, vacuum switching and pilot duty.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally closed
- Port size1/8 in
- Coil voltageAC220V
- Electrical entryFlying lead (lead-out wire type)
- Stations14
- Flow (Cv)0.1
- Series3V2M
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 3V2M Solenoid Valve 3V2MNCAI-14F
The 3V2MNCAI-14F is a fourteen-position NC valve group built on the 3V2M manifold system: every body is a direct-acting, spring-return 3/2 unit with a coaxial popet, and every AC220V coil arrives pre-wired on a flying lead. One supply port serves all fourteen stations, replacing fourteen valves, fourteen fittings and fourteen separate cable drops.
Exhaust here is centralised: all fourteen stations vent through one shared port, so a single silencer and, where needed, one ducted line carry exhaust air away from the panel. The shared supply and shared wiring also speed fault-finding - trace one circuit instead of fourteen, and use each body's manual override to isolate a suspect station. Total energised load is 14 x 7 VA = 98 VA at AC220V. AirtacDistr supplies genuine AirTAC product only.
Airtac 3V2M Solenoid Valve 3V2MNCAI-14F Technical Specifications
| Model | Airtac 3V2M Solenoid Valve 3V2MNCAI-14F |
|---|---|
| Series | 3V2M |
| Valve type | 3/2-way (3-port, 2-position) |
| Function | Direct-acting, single solenoid, spring return |
| Initial state | Normally closed |
| Item form | Complete assembly — 14 valves on a shared base |
| Exhaust | Centralised exhaust |
| Port size | 1/8 in |
| Thread | PT |
| Coil voltage | AC220V |
|---|---|
| Electrical entry | Flying lead (lead-out wire type) |
| Coil power | 7 VA |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
| Vacuum service | Not rated for vacuum |
| Flow coefficient | Cv 0.1 |
| Temperature | -20 to 70 C |
| Construction | Coaxial shut-off (poppet), base-mounted, spring return |
| Protection | IP65 (DIN 40050) |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V2M catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V2M Solenoid Valve 3V2MNCAI-14F
| 3V2M | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NC | Normally closed: no air at the outlet until the coil is energised. |
| AC220V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| I | Electrical entry: I = flying lead, otherwise a DIN plug. |
| 14F | 14 stations in one assembly, centralised exhaust. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V2M Solenoid Valve 3V2MNCAI-14F Is Used
Workshop jig toggles
Bench jigs and drilling fixtures clamp via single-acting cylinders that retract automatically whenever the NC coil drops out.
Palletiser pusher cylinders
Layer-forming pushers on a palletiser cycle from one supply, with a single exhaust silencer serving the entire fourteen-station bank.
Dial-table ejector pins
Part ejection on a rotary assembly table, each of the fourteen positions switched independently from its own coil and lead.
Is the Airtac 3V2M Solenoid Valve 3V2MNCAI-14F the Right Part?
Order against five checkpoints: NC initial state, AC220V voltage code A, flying-lead entry, fourteen stations, centralised exhaust; thread is PT as standard with G and NPT orderable. The NC state is locked at manufacture - flipping the dedicated base gasket does not turn NC into NO, so any position needing air at rest must be ordered as NO.
For sizing, 3V2M trades flow for manifold density at Cv 0.1 per station; step a demanding position out to an individual 3V2 (Cv 0.18 at 1/8 in, 0.19 at 1/4 in, vacuum-rated) or to 3V3 (Cv 0.62, 1/4 in, vacuum-rated), and use 3V1 at 3.0 W DC for low-power light duty. Double-acting cylinders are outside 3/2 duty - the AirTAC 4V series is the right choice there.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V2M Solenoid Valve 3V2MNCAI-14F FAQ
Fourteen 3/2 NC stations, each direct-acting with single solenoid and spring return, Cv 0.1, PT1/8 port, 0-0.8 MPa, -20 to 70 C, AC220V coil at 7 VA, IP65 (DIN 40050), flying-lead entry, centralised exhaust, manual override fitted, medium air filtered to 40 um or finer.
Centralised exhaust vents all fourteen stations through one port - one silencer, tidier panels and easier ducting, but all stations share it. If the process needs each vent kept separate to avoid back-pressure on a shared line, order the independent-exhaust version 3V2MNCAI-14FD instead.
