Airtac 3V2M Solenoid Valve 3V2MNCA-14F
The AirTAC Airtac 3V2M Solenoid Valve 3V2MNCA-14F is a genuine 3-port 2-position (3/2) solenoid valve with 1/8 in ports. It either feeds its outlet or vents it to exhaust, which is what makes it the valve for single-acting cylinders, on/off air blow, clamping, vacuum switching and pilot duty.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally closed
- Port size1/8 in
- Coil voltageAC220V
- Electrical entryDIN plug (DIN socket type)
- Stations14
- Flow (Cv)0.1
- Series3V2M
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 3V2M Solenoid Valve 3V2MNCA-14F
The 3V2MNCA-14F puts fourteen normally closed 3/2 poppet valves on a single 3V2M base, wired from one point and fed from one air supply. Each AC220V coil draws 7 VA, so the worst-case load with all fourteen energised is about 98 VA - size the control transformer for that figure, not for one valve. Ports are PT1/8 and exhaust is centralised through the base.
Because NC stations pass no air until energised, a stopped or powered-down line holds every actuator vented. The coaxial shut-off poppet seals well, and IP65 coils plus manual overrides on each body make installation and commissioning straightforward.
Airtac 3V2M Solenoid Valve 3V2MNCA-14F Technical Specifications
| Model | Airtac 3V2M Solenoid Valve 3V2MNCA-14F |
|---|---|
| Series | 3V2M |
| Valve type | 3/2-way (3-port, 2-position) |
| Function | Direct-acting, single solenoid, spring return |
| Initial state | Normally closed |
| Item form | Complete assembly — 14 valves on a shared base |
| Exhaust | Centralised exhaust |
| Port size | 1/8 in |
| Thread | PT |
| Coil voltage | AC220V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | 7 VA |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
| Vacuum service | Not rated for vacuum |
| Flow coefficient | Cv 0.1 |
| Temperature | -20 to 70 C |
| Construction | Coaxial shut-off (poppet), base-mounted, spring return |
| Protection | IP65 (DIN 40050) |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V2M catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V2M Solenoid Valve 3V2MNCA-14F
| 3V2M | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NC | Normally closed: no air at the outlet until the coil is energised. |
| AC220V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| 14F | 14 stations in one assembly, centralised exhaust. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V2M Solenoid Valve 3V2MNCA-14F Is Used
Carton flap tucking
Drives the flap-tuck and hold-down clamps along a 14-station packaging conveyor, all valves fed from a single air drop.
Fixture clamp matrix
Energises fourteen clamp bolts on a machining fixture in any combination, each releasing to exhaust the moment power drops.
Panel wiring reduction
Replaces fourteen individual valves and their wiring with one base and one connector, simplifying the control panel build.
Is the Airtac 3V2M Solenoid Valve 3V2MNCA-14F the Right Part?
Fourteen stations at Cv 0.1 each makes this the dense option; if any single station must move more air, use a stand-alone 3V2 (Cv 0.18 at 1/8 in, 0.19 at 1/4 in, vacuum-rated) or a 3V3 (Cv 0.62, 1/4 in) for that station. Where the duty is small and power matters, 3V1 at 3.0 W DC is the economical alternative. Double-acting cylinders are outside 3/2 scope - specify the AirTAC 4V series.
Before ordering, fix all five points: NC state, AC220V voltage, DIN plug entry, 14 stations and centralised exhaust, with PT threads (G or NPT by request). The NC state is fixed at the factory and cannot be changed afterwards.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V2M Solenoid Valve 3V2MNCA-14F FAQ
Fourteen 3/2 direct-acting, spring-return stations, Cv 0.1 each, 0-0.8 MPa, -20 to 70 C, AC220V coils at 7 VA (about 98 VA for all 14), IP65 (DIN 40050), PT1/8 ports, centralised exhaust, 40 um filtration or finer.
Every station is a 3-port valve that either feeds the outlet or vents it, so it suits single-acting spring-return cylinders, air blow, clamping and pilot duty. It cannot drive a double-acting cylinder, which needs a 5-port valve such as the AirTAC 4V series. Remember the NC state cannot be converted after purchase.
Authorized Export Seller
Genuine AirTAC parts produced by the AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Fast Dispatch
Standard models are processed and dispatched in 3-5 business days.
Fast Reply
Most inquiries answered within 7-8 hours.
