AirTAC 4V210-06F Solenoid Valve, 5/2-way, PT1/8, DC12V, terminal entry (4V21006F)
The AirTAC AirTAC 4V210-06F Solenoid Valve, 5/2-way, PT1/8, DC12V, terminal entry (4V21006F) is a genuine 5/2-way single solenoid (spring return) solenoid valve with 21006F ports and an effective area of 17.0 mm² (Cv 1.0). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.
- Valve type5/2-way
- FunctionSingle solenoid (spring return)
- Port size21006F
- Effective area17.0 mm²
- Flow (Cv)1.0
- Series4V200
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC 4V210-06F Solenoid Valve, 5/2-way, PT1/8, DC12V, terminal entry (4V21006F)
The AirTAC 4V210-06F is a single-solenoid, 5/2-way pneumatic directional control valve that directs compressed air to double-acting cylinders and actuators. Its spool is shifted by energising the DC12V coil and returned by a mechanical spring when the signal is removed, making it a spring-return design that requires a constant electrical signal to stay in the actuated position.
Built on the 4V200 body, this valve provides an effective area of 17.0 mm2 (Cv 1.0) and typically suits double-acting cylinders in the ~O32-50 mm range. The DC12V coil draws just 2.5 W of power, and the response time is 0.05 seconds or less, giving you crisp, predictable cylinder starts. The 1/8-inch PT porting keeps the footprint compact for space-constrained pneumatic panels.
AirTAC 4V210-06F Solenoid Valve, 5/2-way, PT1/8, DC12V, terminal entry (4V21006F) Technical Specifications
| Model | AirTAC 4V210-06F Solenoid Valve, 5/2-way, PT1/8, DC12V, terminal entry (4V21006F) |
|---|---|
| Series | 4V200 solenoid valve (spool type) |
| Valve type | 5/2-way |
| Function | Single solenoid (spring return) |
| Port size | 21006F |
| Exhaust port | 21006F |
| Effective area (Cv) | 17.0 mm² (Cv 1.0) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Pilot type | Internal / external pilot |
| Operating pressure | 0.15 – 0.8 MPa |
| Proof pressure | 1.2 MPa |
| Max frequency | 5 cycle/sec |
| Response time | ≤ 0.05 s (activating) |
| Temperature | -20 to +70 °C |
| Body material | Aluminum alloy |
| Weight | 220 g |
Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Flow & Coil Options
| Effective area | 17.0 mm² |
|---|---|
| Flow coefficient | Cv 1.0 |
| Response time | ≤ 0.05 s |
| Coil power | AC 4.5 VA · DC24V 3.0 W · DC12V 2.5 W |
| Protection / insulation | IP65 (DIN40050), B-class |
| Voltage options | DC24V, DC12V, AC110V, AC220V |
| Manual override | Yes (locking / non-locking) |
Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.
Model Code: AirTAC 4V210-06F Solenoid Valve, 5/2-way, PT1/8, DC12V, terminal entry (4V21006F)
| 4V | Solenoid valve, spool type, 4-series. |
|---|---|
| 2 | Body size (4V200) — sets port & flow. |
| 1 | Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3. |
| -21006F | Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2". |
Related: 4V210 (single), 4V220 (double), 4V230C/E/P (5/3 center). Add the voltage suffix when ordering.
Where the AirTAC 4V210-06F Solenoid Valve, 5/2-way, PT1/8, DC12V, terminal entry (4V21006F) Is Used
Battery-Powered Assembly Tools
The 2.5 W DC12V coil makes this valve a natural fit for mobile assembly jigs and handheld automation tools running on a 12 V battery supply, controlling a small clamp or press cylinder with minimal power draw.
Compact Sorting Gates
Use the 4V210-06F to drive a double-acting gate cylinder on a small conveyor diverter. The 1/8-inch ports match the tubing typically used for short-stroke, light-load sorting actuators.
Laboratory Test Rigs
In benchtop test fixtures that cycle a pneumatic cylinder repeatedly, the spring-return action ensures the actuator retracts to a home position when the 12 V signal is cut, providing a simple, repeatable sequence.
Is the AirTAC 4V210-06F Solenoid Valve, 5/2-way, PT1/8, DC12V, terminal entry (4V21006F) the Right Valve?
Choose the 4V210-06F when you need a compact 5/2 valve with a DC12V coil for mobile or battery-backed equipment. If your cylinder is smaller than O32 mm, stepping down to the 4V100 series (Cv 0.6) can save space and air consumption; for larger bores or faster cycle rates above 5 cycles per second, the 4V300 body (Cv 1.65) is a better match.
This single-solenoid spring-return configuration is ideal when the valve must default to a known safe position on power loss. When replacing a valve, match all five points: 4V200 body size, 5/2 single-solenoid function, 1/8-inch port with PT thread, DC12V coil voltage, and terminal-style electrical entry. The valve can be used as a standalone unit or mounted on a 4V200 manifold base for multi-valve assemblies.
Quick checklist
- ✓ Required flow (Cv) for cylinder & speed
- ✓ Function: single / double / 5-3 center
- ✓ Coil voltage (DC24 / AC220 …)
- ✓ Port thread (M5 / 1/8 / 1/4 / 3/8 / 1/2)
- ✓ Single valve or manifold base?
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.8 MPa operating pressure.
- check Match coil voltage to your controller output.
- check Use the manual override to test before powering.
- check Fit silencers or fittings to the exhaust ports.
- check Wiring by qualified personnel per AirTAC docs.
AirTAC 4V210-06F Solenoid Valve, 5/2-way, PT1/8, DC12V, terminal entry (4V21006F) FAQ
With an effective area of 17.0 mm2 (Cv 1.0), this 4V200-body valve is well-matched to double-acting cylinders in roughly the O32 to O50 mm bore range for general industrial cycling. Smaller cylinders will work but may cycle faster than needed; larger cylinders will move more slowly and may benefit from the higher Cv of a 4V300 series valve.
Because the 4V210-06F is a single-solenoid valve with a mechanical spring return, the spool immediately shifts back to its home position when the coil is de-energised. This exhausts one side of the double-acting cylinder and pressurises the other, returning the actuator to its default spring-returned state.
