Airtac 4V300 Solenoid Valve 4V330C-10-B
The AirTAC Airtac 4V300 Solenoid Valve 4V330C-10-B is a genuine 5/3-way 5/3 double solenoid — closed center solenoid valve with B ports and an effective area of 21.3 mm² (Cv 1.25). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.
- Valve type5/3-way
- Function5/3 double solenoid — Closed center
- Port sizeB
- Effective area21.3 mm²
- Flow (Cv)1.25
- Series4V300
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 4V300 Solenoid Valve 4V330C-10-B
The AirTAC 4V330C-10B is a 5/3-way double-solenoid valve that directs compressed air to double-acting cylinders and actuators. Its closed-center spool design blocks all ports in the neutral position, holding the cylinder firmly in place when neither solenoid is energized—ideal for applications where a load must not drift during a mid-cycle stop.
Built on the 4V300 aluminum body with 3/8-inch PT ports, this model carries a DC24V coil drawing just 3.0 W. The effective area of 21.3 mm² (Cv 1.25) pairs well with bores in the ~50-80 mm range, while the sub-0.05-second response keeps cycle times tight.
Airtac 4V300 Solenoid Valve 4V330C-10-B Technical Specifications
| Model | Airtac 4V300 Solenoid Valve 4V330C-10-B |
|---|---|
| Series | 4V300 solenoid valve (spool type) |
| Valve type | 5/3-way |
| Function | 5/3 double solenoid — Closed center |
| Port size | B |
| Exhaust port | B |
| Effective area (Cv) | 21.3 mm² (Cv 1.25) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Pilot type | Internal / external pilot |
| Operating pressure | 0.15 – 0.8 MPa |
| Proof pressure | 1.2 MPa |
| Max frequency | 3 cycle/sec |
| Response time | ≤ 0.05 s (activating) |
| Temperature | -20 to +70 °C |
| Body material | Aluminum alloy |
| Weight | 450 g |
Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Flow & Coil Options
| Effective area | 21.3 mm² |
|---|---|
| Flow coefficient | Cv 1.25 |
| Response time | ≤ 0.05 s |
| Coil power | AC 4.5 VA · DC24V 3.0 W · DC12V 2.5 W |
| Protection / insulation | IP65 (DIN40050), B-class |
| Voltage options | DC24V, DC12V, AC110V, AC220V |
| Manual override | Yes (locking / non-locking) |
Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.
Model Code: Airtac 4V300 Solenoid Valve 4V330C-10-B
| 4V | Solenoid valve, spool type, 4-series. |
|---|---|
| 3 | Body size (4V300) — sets port & flow. |
| 3 | Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3. |
| -B | Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2". |
Related: 4V310 (single), 4V320 (double), 4V330C/E/P (5/3 center). Add the voltage suffix when ordering.
Where the Airtac 4V300 Solenoid Valve 4V330C-10-B Is Used
Clamping Stations
Holds pneumatic clamps steady at mid-cycle on CNC fixtures or welding jigs, preventing part shift when the valve centers.
Pallet Stop Gates
Controls a lift-and-stop gate on a conveyor line, locking the cylinder in the raised position to safely hold a pallet.
Vertical Press Safety
Keeps a press ram from drifting downward at the neutral point, adding a layer of control for tool-change or setup positions.
Is the Airtac 4V300 Solenoid Valve 4V330C-10-B the Right Valve?
Choose the 4V330C-10B when you need a 5/3 closed-center function on a 3/8-inch ported base. If your cylinder is smaller, the 4V200 series offers a lighter Cv 1.0 alternative; for larger bores, step up to the 4V400 at Cv 2.82. This double-solenoid valve holds its last position on power loss, but remember the closed center means the cylinder is locked at mid-stroke—not just stopped. Match the DC24V coil, PT thread, and terminal-box entry when replacing an existing unit.
Quick checklist
- ✓ Required flow (Cv) for cylinder & speed
- ✓ Function: single / double / 5-3 center
- ✓ Coil voltage (DC24 / AC220 …)
- ✓ Port thread (M5 / 1/8 / 1/4 / 3/8 / 1/2)
- ✓ Single valve or manifold base?
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.8 MPa operating pressure.
- check Match coil voltage to your controller output.
- check Use the manual override to test before powering.
- check Fit silencers or fittings to the exhaust ports.
- check Wiring by qualified personnel per AirTAC docs.
Airtac 4V300 Solenoid Valve 4V330C-10-B FAQ
In the center position, all ports are blocked. The cylinder is held in place and cannot be moved by hand or external force, unlike an exhaust-center valve which would allow it to float.
No, the -B suffix means this specific model requires a 24V DC power supply. Using AC voltage will damage the 3.0 W coil. For AC, choose a model like the 4V330C-10A.
