AirTAC 4V410-15EI Solenoid Valve, 5/2-way, PT1/2, AC24V, grommet entry (4V41015EI)
The AirTAC AirTAC 4V410-15EI Solenoid Valve, 5/2-way, PT1/2, AC24V, grommet entry (4V41015EI) is a genuine 5/2-way single solenoid (spring return) solenoid valve with 41015EI ports and an effective area of 48.0 mm² (Cv 2.82). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.
- Valve type5/2-way
- FunctionSingle solenoid (spring return)
- Port size41015EI
- Effective area48.0 mm²
- Flow (Cv)2.82
- Series4V400
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC 4V410-15EI Solenoid Valve, 5/2-way, PT1/2, AC24V, grommet entry (4V41015EI)
The 4V410-15EI is a 5/2-way single-solenoid pneumatic directional valve that directs compressed air to double-acting cylinders and actuators. Its spool shifts when the AC24V coil is energised, and a mechanical spring returns it to the home position the moment power is removed—making it a safe default for applications where the cylinder must retract or stop on power loss.
Built on the largest 4V body size, this valve delivers an effective area of 48.0 mm² (Cv 2.82) and weighs 590 g. The 'EI' configuration pairs an AC24V coil (5.0 VA) with a grommet-style electrical entry that provides a 0.5 m pre-wired flying lead, simplifying installation on machines where a terminal box is hard to reach. Response time is 0.05 s or less, and the IP65-rated enclosure handles washdown and dusty environments.
AirTAC 4V410-15EI Solenoid Valve, 5/2-way, PT1/2, AC24V, grommet entry (4V41015EI) Technical Specifications
| Model | AirTAC 4V410-15EI Solenoid Valve, 5/2-way, PT1/2, AC24V, grommet entry (4V41015EI) |
|---|---|
| Series | 4V400 solenoid valve (spool type) |
| Valve type | 5/2-way |
| Function | Single solenoid (spring return) |
| Port size | 41015EI |
| Exhaust port | 41015EI |
| Effective area (Cv) | 48.0 mm² (Cv 2.82) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Pilot type | Internal / external pilot |
| Operating pressure | 0.15 – 0.8 MPa |
| Proof pressure | 1.2 MPa |
| Max frequency | 3 cycle/sec |
| Response time | ≤ 0.05 s (activating) |
| Temperature | -20 to +70 °C |
| Body material | Aluminum alloy |
| Weight | 590 g |
Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Flow & Coil Options
| Effective area | 48.0 mm² |
|---|---|
| Flow coefficient | Cv 2.82 |
| Response time | ≤ 0.05 s |
| Coil power | AC 4.5 VA · DC24V 3.0 W · DC12V 2.5 W |
| Protection / insulation | IP65 (DIN40050), B-class |
| Voltage options | DC24V, DC12V, AC110V, AC220V |
| Manual override | Yes (locking / non-locking) |
Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.
Model Code: AirTAC 4V410-15EI Solenoid Valve, 5/2-way, PT1/2, AC24V, grommet entry (4V41015EI)
| 4V | Solenoid valve, spool type, 4-series. |
|---|---|
| 4 | Body size (4V400) — sets port & flow. |
| 1 | Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3. |
| -41015EI | Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2". |
Related: 4V410 (single), 4V420 (double), 4V430C/E/P (5/3 center). Add the voltage suffix when ordering.
Where the AirTAC 4V410-15EI Solenoid Valve, 5/2-way, PT1/2, AC24V, grommet entry (4V41015EI) Is Used
Large Conveyor Diverters
Drives pneumatic gates and diverters on wide conveyor lines. The spring-return action ensures the diverter retracts to a safe position if AC power is interrupted, preventing product jams.
Heavy-Duty Clamping Systems
Controls a double-acting clamp on a welding or assembly fixture. The 4V400's Cv 2.82 fills a large-bore cylinder quickly, and the AC24V grommet lead simplifies wiring into crowded machine junction boxes.
Palletiser Air Circuits
Operates the lift and sweep cylinders on a palletising cell. The spring-return 5/2 function guarantees the sweep arm retracts on E-stop, while the IP65 body withstands dusty warehouse air.
Is the AirTAC 4V410-15EI Solenoid Valve, 5/2-way, PT1/2, AC24V, grommet entry (4V41015EI) the Right Valve?
Choose the 4V410-15EI when you need a large-bore 5/2 spring-return function with AC24V control power and a pre-wired grommet connection. The 4V400 body is the highest-flow member of the 4V family; if your cylinder is smaller than ~O80 mm, stepping down to a 4V300 (Cv 1.65) often yields a more compact, lower-cost installation. For still larger flow demands beyond this 1/2-inch valve, consider moving to a manifolded bank or a larger valve series.
When replacing an existing valve, match five points: body size (4V400), function (single solenoid 5/2), port size and thread (1/2 inch PT), coil voltage (AC24V), and electrical entry (grommet with flying lead). A mismatch on any of these—particularly voltage or entry style—will prevent a drop-in fit.
Quick checklist
- ✓ Required flow (Cv) for cylinder & speed
- ✓ Function: single / double / 5-3 center
- ✓ Coil voltage (DC24 / AC220 …)
- ✓ Port thread (M5 / 1/8 / 1/4 / 3/8 / 1/2)
- ✓ Single valve or manifold base?
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.8 MPa operating pressure.
- check Match coil voltage to your controller output.
- check Use the manual override to test before powering.
- check Fit silencers or fittings to the exhaust ports.
- check Wiring by qualified personnel per AirTAC docs.
AirTAC 4V410-15EI Solenoid Valve, 5/2-way, PT1/2, AC24V, grommet entry (4V41015EI) FAQ
With an effective area of 48.0 mm² (Cv 2.82), this 4V400 valve suits double-acting cylinders roughly in the O80 to O125 mm range for typical industrial cycle rates. It is the largest body in the 4V family; for smaller O50–O63 mm cylinders a 4V300 valve is often a better match.
'E' specifies an AC24V coil (5.0 VA power consumption), and 'I' denotes a grommet-style electrical entry with a 0.5 m pre-wired flying lead. This is a popular choice when a DIN connector or terminal box is impractical due to space constraints or vibration.
