Airtac ACED Double-acting Compact Cylinder ACED100X10
The AirTAC Airtac ACED Double-acting Compact Cylinder ACED100X10 is a genuine double acting, double rod ISO 21287 compact air cylinder with a Ø100mm bore and 10mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke10 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACED Double-acting Compact Cylinder ACED100X10
A double acting compact cylinder built to ISO 21287, the ACED100X10 pushes a 100 mm bore through a short 10 mm stroke with a piston rod leaving BOTH covers. Because each side works on the rod-side area, output is identical in either direction: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa, with a peak of 768.8 kgf at 1.0 MPa. The hard-anodized aluminium body pairs with an S45C hard-chrome-plated rod and a fixed TPU bumper at each end to soak up end-of-stroke shock.
The through-rod is the working advantage here: it resists rotation and side load, gives a symmetric mount, and the rear rod can carry a sensor flag on a clamping or press-fit station. As a rule of thumb, keep real work near 2262 N at 0.5 MPa, which corresponds to lifting roughly 192 kg vertically with a 2:1 margin. The short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into tight press benches and guarded cells. Note that position is not held if air is lost - add a rod lock or pilot check for a held load.
Airtac ACED Double-acting Compact Cylinder ACED100X10 Technical Specifications
| Model | Airtac ACED Double-acting Compact Cylinder ACED100X10 |
|---|---|
| Series | ACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 10 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACED Double-acting Compact Cylinder ACED100X10
| ACED | ISO 21287 compact cylinder (double-rod). |
|---|---|
| 100 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACED Double-acting Compact Cylinder ACED100X10 Is Used
Short-stroke press station
A 10 mm stroke delivering 3769.9 N both ways suits staking, marking or swaging heads on an electronics assembly bench where full-length cylinders cannot fit under the press frame.
Symmetric part ejector
With a rod on each cover, the same 5277.9 N at 0.7 MPa can push a machined housing off a fixture from either side, and the rear rod doubles as a mount for a position flag.
Clamp-and-lift pallet riser
On a pallet transfer line, the through-rod resists the side load of a rising platen while the bore's lift capacity of about 192 kg vertically (with margin) handles loaded trays.
Is the Airtac ACED Double-acting Compact Cylinder ACED100X10 the Right Cylinder?
At 3769.9 N per direction, this bore sits between the 80 mm frame (2356.2 N) and the 125 mm frame (5890.5 N) at 0.5 MPa, so pick it when a 10 mm clamp or eject stroke needs serious force in a short envelope. Air supply is 0.15-1.0 MPa (22-145 psi) through a 1/4" port, speed 30-500 mm/s. The female M12x1.75 rod thread on both ends accepts standard rod knuckles (I or Y); FA/FB flanges, LB feet and FTC brackets bolt to the ISO 21287 face. This code has no magnet - order the -S version if you need CMSE / DMSE switch sensing.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACED Double-acting Compact Cylinder ACED100X10 FAQ
Yes - the double-rod design means both strokes use the rod-side area, so output is equal each way: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa, peaking at 768.8 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi), proof 1.5 MPa (215 psi), speed 30-500 mm/s, air filtered to 40 um, temperature -20 to +70 C.
The ISO 21287 short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, and FA/FB flange, LB foot and FTC brackets bolt straight to its face. Sensing requires the optional -S magnet code: this ACED100X10 has no magnet fitted, so order ACED100X10S to run CMSE or DMSE switches along the body slots.
