Airtac ACED Double-acting Compact Cylinder ACED100X100B
The AirTAC Airtac ACED Double-acting Compact Cylinder ACED100X100B is a genuine double acting, double rod ISO 21287 compact air cylinder with a Ø100mm bore and 100mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke100 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACED Double-acting Compact Cylinder ACED100X100B
A double acting compact cylinder built to ISO 21287, the ACED100X100B pushes a 100 mm bore through a 100 mm stroke with a 20 mm rod leaving BOTH covers. Because each side sees the rod-side area, output is 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa in either direction - never more one way than the other. The male rod thread (B code) bolts straight to tooling, and the through-rod resists rotation and side load while the rear rod can carry a sensor flag.
The hard-anodized aluminium body with an S45C hard-chrome rod runs on air filtered to 40 um at 0.15-1.0 MPa (22-145 psi), 30-500 mm/s, -20 to 70 C, with a fixed TPU bumper at each end. The short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into presses and gantries where a full-length body cannot. As a planning figure, treat roughly 2260 N as usable work at 0.5 MPa - enough to lift about 115 kg vertically with a 2:1 margin.
Airtac ACED Double-acting Compact Cylinder ACED100X100B Technical Specifications
| Model | Airtac ACED Double-acting Compact Cylinder ACED100X100B |
|---|---|
| Series | ACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACED Double-acting Compact Cylinder ACED100X100B
| ACED | ISO 21287 compact cylinder (double-rod). |
|---|---|
| 100 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACED Double-acting Compact Cylinder ACED100X100B Is Used
Stamping press ejector
The 3769.9 N both-ways output at 0.5 MPa ejects formed steel blanks from a die on the forward stroke and retracts the pusher plate with identical force, inside a 100 mm window.
Pallet strapper tensioner
A symmetric through-rod clamps PET strapping from both sides of the frame; the 20 mm rod resists the side pull of the tension head at 30-500 mm/s cycle speeds.
Robot gripper counterweight lift
The rear rod balances a welding-cell fixture: with about 115 kg of vertical lift capacity at a 2:1 margin, the second rod end carries the counterweight while the front rod does the work.
Is the Airtac ACED Double-acting Compact Cylinder ACED100X100B the Right Cylinder?
At 3769.9 N per side at 0.5 MPa this bore sits well above the 63 mm size (1458.1 N) and below the 125 mm size (5890.5 N), so choose it when a 63 mm frame is undersized but the 125 mm body will not fit the envelope. Remember it does not hold position if air is lost - add a rod lock or pilot check for a suspended load. Mount with FA/FB flange, LB foot or FTC brackets plus I/Y rod knuckles on the ISO 21287 face. This unit has no magnet; order the -S code if you need CMSE / DMSE switch positions.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACED Double-acting Compact Cylinder ACED100X100B FAQ
Yes - equal both ways, because a rod exits each cover and both strokes use the rod-side area of the 100 mm bore. Figures: 3769.9 N at 0.5 MPa, 5277.9 N at 0.7 MPa, and a maximum of 768.8 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi) with proof pressure of 1.5 MPa (215 psi).
A fixed TPU bumper at each cover absorbs end-of-stroke energy; it is not adjustable and never locks a load - use a rod lock or pilot check if the piston must hold when air is lost. This ACED100X100B has no magnet fitted; ordering the optional -S version embeds a magnet so CMSE / DMSE switches can read position along the body slots.
