Airtac ACED Double-acting Compact Cylinder ACED100X10SB
The AirTAC Airtac ACED Double-acting Compact Cylinder ACED100X10SB is a genuine double acting, double rod ISO 21287 compact air cylinder with a Ø100mm bore and 10mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke10 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACED Double-acting Compact Cylinder ACED100X10SB
A double acting, double-rod compact cylinder built to ISO 21287, the ACED100X10SB pushes a 100 mm piston through a 10 mm stroke and delivers 3769.9 N in BOTH directions at 0.5 MPa (5277.9 N at 0.7 MPa), because each side of the piston sees the rod-side area. The 20 mm hard-chrome-plated S45C rod exits both covers, so the through-rod resists rotation and side load while the rear rod gives you a ready mounting point for a sensor flag. A male M12x1.25-class rod thread (the B code) and 1/4" PT ports complete the fluid side.
The short ISO 21287 body saves about 50% of the mounting length of an ISO 15552 profile cylinder, which is why this bore class fits tight press fixtures and gantry clamps that a full-length body cannot. In practice, plan on roughly 2262 N (about 230 kgf) of usable work at 0.5 MPa, or around 192 kg of vertical lift with a 2:1 margin. The hard-anodized aluminium body carries the optional -S magnet on this model, so CMSE / DMSE switches mount directly, and fixed TPU bumpers at both ends absorb end-of-stroke shock. Speed range is 30-500 mm/s over 0.15-1.0 MPa (22-145 psi).
Airtac ACED Double-acting Compact Cylinder ACED100X10SB Technical Specifications
| Model | Airtac ACED Double-acting Compact Cylinder ACED100X10SB |
|---|---|
| Series | ACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 10 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACED Double-acting Compact Cylinder ACED100X10SB
| ACED | ISO 21287 compact cylinder (double-rod). |
|---|---|
| 100 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACED Double-acting Compact Cylinder ACED100X10SB Is Used
Short-stroke press fixture
A 10 mm stroke with 3769.9 N both ways at 0.5 MPa is ideal for a staking or marking head on an aluminium extrusion line, where the compact body tucks under a fixed guard.
Reciprocating shuttle carriage
The through-rod lets a pick-and-place carriage ride between two rod ends on a PCB transfer unit, resisting rotation over the 30-500 mm/s speed band.
Clamp-and-lift elevator pin
Lifts about 192 kg vertically with a 2:1 margin, suiting a pallet elevator pin in a warehouse conveyor that needs equal force up and down.
Is the Airtac ACED Double-acting Compact Cylinder ACED100X10SB the Right Cylinder?
Size both ways: if 3769.9 N at 0.5 MPa is more than your jig needs, the ACED63X10SB gives 1458.1 N in the same short-body format; if you need more, the ACED125X10SB reaches 5890.5 N. Remember this is a plain double-rod cylinder - it does not hold position when air is lost, so add a rod lock or pilot check for a suspended load. FA/FB flanges, LB feet and FTC brackets bolt straight to the ISO 21287 face, and I/Y rod knuckles suit the male-threaded rod. The -S magnet is already fitted on this code for CMSE / DMSE switching.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACED Double-acting Compact Cylinder ACED100X10SB FAQ
Because a rod exits both covers, output is equal both ways: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa, on the rod-side area. Peak output at 1.0 MPa is about 768.8 kgf. Operating pressure is 0.15-1.0 MPa (22-145 psi), proof pressure 1.5 MPa (215 psi), with a 20 mm rod and 1/4" PT ports.
The ISO 21287 body is a hard-anodized aluminium tube with threaded covers, about 50% shorter in mounting length than an ISO 15552 profile cylinder, and fixed TPU bumpers at each end absorb end-of-stroke energy. This code carries the optional -S magnet, so CMSE / DMSE reed or solid-state switches can be clipped into the body slots to signal end positions.
