Airtac ACED Double-acting Compact Cylinder ACED100X110
The AirTAC Airtac ACED Double-acting Compact Cylinder ACED100X110 is a genuine double acting, double rod ISO 21287 compact air cylinder with a Ø100mm bore and 110mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke110 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACED Double-acting Compact Cylinder ACED100X110
A double acting compact cylinder built to ISO 21287, the ACED100X110 pushes a 100 mm bore through a 110 mm stroke with a rod leaving BOTH covers, so thrust is identical on the out-stroke and the return: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa. The through-rod resists rotation and side load and gives a symmetric mount, and the back-end rod can carry a sensor flag. Air supply is 0.15-1.0 MPa (22-145 psi), speed range 30-500 mm/s.
The short ISO 21287 body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so this 100 mm bore fits presses and gantries where a full-length body will not. Hard-anodized aluminium body, S45C hard-chrome plated rod, fixed TPU bumper at each end. Plan on roughly 2260 N of real work at 0.5 MPa, and for vertical duty expect to lift about 192 kg with a 2:1 margin. Ports are 1/4"; the female rod thread is M12x1.75.
Airtac ACED Double-acting Compact Cylinder ACED100X110 Technical Specifications
| Model | Airtac ACED Double-acting Compact Cylinder ACED100X110 |
|---|---|
| Series | ACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 110 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACED Double-acting Compact Cylinder ACED100X110
| ACED | ISO 21287 compact cylinder (double-rod). |
|---|---|
| 100 | Bore size in mm. |
| ×110 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACED Double-acting Compact Cylinder ACED100X110 Is Used
Pneumatic press station
The 3769.9 N both-ways thrust at 0.5 MPa swages and stakes aluminium terminals in a 110 mm stroke window inside a tight press frame.
Pallet lift-and-lower column
A rod on each face lets one cylinder raise a 190 kg pallet fixture and pull it back down with the same force, no separate return spring cylinder needed.
Symmetric slider drive
The through-rod drives a linear guide carriage from both sides on a packaging machine, resisting rotation at speeds up to 500 mm/s.
Is the Airtac ACED Double-acting Compact Cylinder ACED100X110 the Right Cylinder?
At 3769.9 N per side at 0.5 MPa this bore sits between the 80 mm (2356.2 N) and 125 mm (5890.5 N) sizes, so step down for lighter clamps or up for heavy press work. Remember the piston drifts if air is lost - add a rod lock or pilot check valve where the load must stay put. FA/FB flange, LB foot and FTC brackets plus I/Y rod knuckles bolt to the ISO 21287 face. This code has no magnet; order the -S version if you need CMSE / DMSE switch position feedback.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACED Double-acting Compact Cylinder ACED100X110 FAQ
Yes - the double-rod design means both strokes use the rod-side area, so output is equal either way: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa, peaking at 768.8 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi), proof 1.5 MPa (215 psi), speed 30-500 mm/s, air filtered to 40 um.
It is an ISO 21287 compact cylinder whose short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, with a fixed TPU bumper at each end and FA/FB, LB and FTC mounting options. Position sensing needs the optional -S magnet code; this version has no magnet, so CMSE / DMSE switches cannot be fitted unless -S is ordered.
