Airtac ACED Double-acting Compact Cylinder ACED100X110S
The AirTAC Airtac ACED Double-acting Compact Cylinder ACED100X110S is a genuine double acting, double rod ISO 21287 compact air cylinder with a Ø100mm bore and 110mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke110 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACED Double-acting Compact Cylinder ACED100X110S
A double acting compact cylinder with a rod leaving both covers, the ACED100X110S delivers 3769.9 N in either direction at 0.5 MPa because both strokes work on the rod-side area. The 100 mm bore runs on 0.15-1.0 MPa (22-145 psi) air filtered to 40 um, at speeds of 30-500 mm/s, with a fixed TPU bumper at each end to soften the stroke ends.
The hard-anodized aluminium body is an ISO 21287 short build, saving about 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into presses and fixtures where a full-length body will not go. The through-rod resists rotation and side load and gives a symmetric mount, and the back rod can carry a sensor flag. As a rough guide, plan on about 2260 N of real work at 0.5 MPa, which lifts roughly 192 kg vertically with a 2:1 margin. The -S code on this model means the magnet is fitted, so CMSE / DMSE switches can be clamped straight into the body slots.
Airtac ACED Double-acting Compact Cylinder ACED100X110S Technical Specifications
| Model | Airtac ACED Double-acting Compact Cylinder ACED100X110S |
|---|---|
| Series | ACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 110 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACED Double-acting Compact Cylinder ACED100X110S
| ACED | ISO 21287 compact cylinder (double-rod). |
|---|---|
| 100 | Bore size in mm. |
| ×110 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACED Double-acting Compact Cylinder ACED100X110S Is Used
Baler ram with return-side sensor
The 3769.9 N both-way force compacts cartons or scrap in a small baler, and the fitted magnet plus a CMSE switch on the rear rod confirms full retraction before the next cycle.
Pallet-stacker pusher arm
A through-rod pushing a 190 kg pallet bin off a stacker fork stays straight under side load, and the 110 mm stroke clears the bin in one move at 30-500 mm/s.
Twin-clamp welding fixture
Both rod ends carry clamp arms on a car-body welding jig, giving equal 5277.9 N clamping at 0.7 MPa on each side from one compact ISO 21287 body.
Is the Airtac ACED Double-acting Compact Cylinder ACED100X110S the Right Cylinder?
At 3769.9 N per stroke, this bore sits between the 80 mm frame (2356.2 N at 0.5 MPa) and the 125 mm frame (5890.5 N at 0.5 MPa), so pick the 80 if your load is under about 1400 N of working force and step to 125 only when the 100 leaves no margin. The 110 mm stroke is well inside the 300 mm standard limit for this bore, so no made-to-order build is needed.
Remember the piston drifts if air is lost - for a held vertical load add a rod lock or pilot check valve. Mount with FA/FB flange, LB foot or FTC brackets, and I or Y rod knuckles on the female M12x1.25 thread end. Note the female rod thread for this bore is M12x1.75; confirm the exact drawing from the datasheet before machining your fixture.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACED Double-acting Compact Cylinder ACED100X110S FAQ
Yes - the double-rod design puts a 20 mm rod on both covers, so every stroke uses the rod-side area. Output is 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa, equal in both directions, with a peak of 768.8 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi), proof pressure 1.5 MPa (215 psi), speed 30-500 mm/s, and the 110 mm stroke sits inside the 300 mm standard limit for this bore.
The -S means the optional magnet is fitted on this model, so CMSE or DMSE reed or solid-state switches clamp into the body slots for end-of-stroke signals. Mechanically you get a hard-anodized aluminium ISO 21287 compact body about 50% shorter in mounting length than an ISO 15552 profile cylinder, an S45C hard-chrome rod, a fixed TPU bumper at each end, a 1/4" air port, and FA/FB flange, LB foot or FTC mounting faces.
