Airtac ACED Double-acting Compact Cylinder ACED100X120
The AirTAC Airtac ACED Double-acting Compact Cylinder ACED100X120 is a genuine double acting, double rod ISO 21287 compact air cylinder with a Ø100mm bore and 120mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke120 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACED Double-acting Compact Cylinder ACED100X120
A double acting compact cylinder built to ISO 21287, the ACED100X120 uses a 100 mm bore with a rod leaving both covers, so thrust is identical on the extend and retract strokes. At 0.5 MPa it delivers 3769.9 N in either direction, rising to 5277.9 N at 0.7 MPa. The through-rod resists rotation and side load and gives a symmetric mount, and the rear rod can carry a sensor flag on gantry and press fixtures.
The hard-anodized aluminium body with an S45C hard-chrome plated rod runs on air filtered to 40 um at 0.15-1.0 MPa (22-145 psi), 30-500 mm/s, from -20 to +70 C. Its short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into tight machine frames. A fixed TPU bumper at each end absorbs end-of-stroke shock. As a working figure, plan on roughly 2262 N of real work at 0.5 MPa, which is about 115 kg of vertical lift with a 2:1 margin.
Airtac ACED Double-acting Compact Cylinder ACED100X120 Technical Specifications
| Model | Airtac ACED Double-acting Compact Cylinder ACED100X120 |
|---|---|
| Series | ACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 120 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACED Double-acting Compact Cylinder ACED100X120
| ACED | ISO 21287 compact cylinder (double-rod). |
|---|---|
| 100 | Bore size in mm. |
| ×120 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACED Double-acting Compact Cylinder ACED100X120 Is Used
Press transfer lift
The 3769.9 N both-ways output raises and lowers a stamping shuttle between press stations, and the equal retract force pulls the part back down without a return spring.
Gantry Z-axis clamp
A symmetric through-rod mount on a CNC gantry holds a clamping beam level, with the rear rod carrying a flag for position checks.
Pallet ejector
On a packaging line, the 120 mm stroke pushes loaded pallets off a conveyor lane, and the compact body fits where a full-length profile cylinder cannot.
Is the Airtac ACED Double-acting Compact Cylinder ACED100X120 the Right Cylinder?
Step down to the ACED63X120 if 1458.1 N at 0.5 MPa covers the job; step up to the ACED125X120 when 5890.5 N is needed. Both keep the same 120 mm stroke. Note that this plain double-rod cylinder drifts when air is lost, so add a rod lock or pilot check for a held load. Mount it with FA/FB flange or LB foot brackets on the ISO 21287 face, and order the -S code if CMSE / DMSE switch positions are wanted - without -S there is no magnet fitted.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACED Double-acting Compact Cylinder ACED100X120 FAQ
Output is equal in both directions because a rod exits each cover and both strokes use the rod-side area: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa, with a maximum of 768.8 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi), proof pressure 1.5 MPa (215 psi), speed 30-500 mm/s, and the 1/4" port depends only on the 100 mm bore.
It is an ISO 21287 compact cylinder whose short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, with a fixed TPU bumper at each end to absorb end-of-stroke energy. Position sensing needs the optional -S magnet code; only then can CMSE / DMSE switches be clipped to the body. Without -S no magnet is fitted.
