Airtac ACED Double-acting Compact Cylinder ACED100X120B
The AirTAC Airtac ACED Double-acting Compact Cylinder ACED100X120B is a genuine double acting, double rod ISO 21287 compact air cylinder with a Ø100mm bore and 120mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke120 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACED Double-acting Compact Cylinder ACED100X120B
This double acting compact cylinder carries a rod through BOTH covers, so the 100 mm bore delivers the same 3769.9 N at 0.5 MPa (5277.9 N at 0.7 MPa) whether it pushes or pulls - both strokes work on the rod-side area. The male rod thread (B code) on each 20 mm rod end accepts standard rod accessories directly. Running on 0.15-1.0 MPa (22-145 psi) filtered air at 30-500 mm/s, it suits heavy clamping and press-fit work.
The ISO 21287 short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, which matters in wide gantries and press frames where every millimetre of envelope counts. The hard-anodized aluminium body carries FA/FB flange and LB foot brackets plus I/Y rod knuckles on the standard face. A fixed TPU bumper at each end absorbs stroke-end shock, and the through-rod resists rotation so the back rod can carry a sensor flag. Plan on roughly 2262 N of usable work at 0.5 MPa - about 230 kg of vertical force - rather than the full rating.
Airtac ACED Double-acting Compact Cylinder ACED100X120B Technical Specifications
| Model | Airtac ACED Double-acting Compact Cylinder ACED100X120B |
|---|---|
| Series | ACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 120 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACED Double-acting Compact Cylinder ACED100X120B
| ACED | ISO 21287 compact cylinder (double-rod). |
|---|---|
| 100 | Bore size in mm. |
| ×120 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACED Double-acting Compact Cylinder ACED100X120B Is Used
Press-frame part ejection
The through-rod ejects stamped housings from a die on the forward stroke while the rear rod retracts a scraper plate, both at 3769.9 N at 0.5 MPa.
Gantry pick-and-place counterbalance
Mounted in a narrow gantry over a packaging line, the symmetric rods carry a gripper and its counterweight, lifting parts of about 115 kg with a 2:1 margin.
Reciprocating test rig actuator
A durability test bench cycles a gearbox shifter at 30-500 mm/s; the back rod drives a position flag and the TPU bumpers absorb each reversal.
Is the Airtac ACED Double-acting Compact Cylinder ACED100X120B the Right Cylinder?
Size both ways: a 63 mm double-rod unit gives 1458.1 N at 0.5 MPa, while the 125 mm bore reaches 5890.5 N - pick the 100 mm when you need about 3.8 kN in a short envelope. Remember the piston drifts when air is lost; for a held load add a rod lock or pilot check valve. This code has no magnet, so CMSE / DMSE switches cannot be fitted - order the -S variant if position sensing is needed. PT ports, 1/4", and a 300 mm maximum standard stroke for this bore.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACED Double-acting Compact Cylinder ACED100X120B FAQ
Yes - the double-rod design means both strokes use the rod-side area, so output is equal either way: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa, with a maximum of 768.8 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi) with proof pressure of 1.5 MPa (215 psi).
The ISO 21287 short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, with a hard-anodized aluminium body, S45C hard-chrome plated rods and fixed TPU bumpers at both stroke ends. FA/FB flanges, LB feet and I/Y knuckles bolt to the standard face. Sensing needs the optional -S magnet code; this unit has no magnet, so CMSE / DMSE switches cannot be mounted on it.
