Airtac ACED Double-acting Compact Cylinder ACED100X160
The AirTAC Airtac ACED Double-acting Compact Cylinder ACED100X160 is a genuine double acting, double rod ISO 21287 compact air cylinder with a Ø100mm bore and 160mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke160 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACED Double-acting Compact Cylinder ACED100X160
A double acting compact cylinder built to ISO 21287, the ACED100X160 pushes a 100 mm bore through a 160 mm stroke with a rod leaving BOTH covers, so thrust is identical on each stroke - 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa. The through-rod resists rotation and side load and gives a symmetric mount, and the rear rod can carry a sensor flag on clamping fixtures.
The short hard-anodized aluminium body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into tight presses and gantries. At 0.5 MPa plan on roughly 2262 N of usable work, which lifts about 192 kg vertically with a 2:1 margin. The S45C hard-chrome rod, TPU bumper at both ends and 30-500 mm/s speed range round out the spec; the optional -S magnet enables CMSE / DMSE switches.
Airtac ACED Double-acting Compact Cylinder ACED100X160 Technical Specifications
| Model | Airtac ACED Double-acting Compact Cylinder ACED100X160 |
|---|---|
| Series | ACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 160 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACED Double-acting Compact Cylinder ACED100X160
| ACED | ISO 21287 compact cylinder (double-rod). |
|---|---|
| 100 | Bore size in mm. |
| ×160 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACED Double-acting Compact Cylinder ACED100X160 Is Used
Baler ram return sync
Equal 3769.9 N force on both strokes keeps a small recycling-baler platen balanced on extend and retract, with the through-rod guiding the platen against side load.
Pallet-stacker mast assist
About 192 kg of vertical lift capacity at a 2:1 margin suits counterbalance arms on warehouse stacker masts within the 160 mm stroke.
Twin-sided weld fixture
A rod on each cover lets one cylinder clamp from both faces of an automotive weld fixture, halving valve count on the fixture plate.
Is the Airtac ACED Double-acting Compact Cylinder ACED100X160 the Right Cylinder?
At 3769.9 N at 0.5 MPa this bore sits between the 80 mm (2356.2 N) and 125 mm (5890.5 N) sizes - step down for lighter clamps, up for heavy die work. Remember it drifts when air is lost; add a rod lock or pilot check for a held load. FA/FB flange, LB foot and FTC brackets bolt to the ISO 21287 face, and the female M12x1.75 rod thread takes standard I/Y knuckles. Order the -S code if you need CMSE / DMSE switching.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACED Double-acting Compact Cylinder ACED100X160 FAQ
Because a rod exits both covers, output is EQUAL both ways: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa, with a maximum of 768.8 kgf at 1.0 MPa. Operating pressure is 0.15-1.0 MPa (22-145 psi), proof 1.5 MPa (215 psi), speed 30-500 mm/s, air filtered to 40 um, -20 to +70 C.
The ISO 21287 short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, with a fixed TPU bumper at each end to absorb end-of-stroke energy. Sensing needs the optional -S magnet at order time - without it no CMSE / DMSE switch can be mounted. FA/FB flange, LB foot and FTC brackets fit the standard face.
