Airtac GAC F.R.L. Unit GAC20006SN
The AirTAC Airtac GAC F.R.L. Unit GAC20006SN is a genuine three-unit F.R.L. combination — a filter, a pressure regulator and a lubricator pre-assembled on one bracket with quick mounting clamps. It has 1/8" ports, a 40 µm filter element and regulates 0.15 - 0.9 MPa (20 - 130 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade40 µm
- Bowl materialPC
- Drainsemi-auto + manual
- Pressure gaugeNot fitted
- Weight750 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAC F.R.L. Unit GAC20006SN
Delivering cleaned, regulated and lubricated air for light-duty pneumatics, this GAC20006SN assembly integrates a filter, regulator and lubricator on a single L-shape bracket. The 1/8in port feeds the 0.15-0.9 MPa (20-130 psi) standard pressure range, passing air through a 40 um element. Because the lubricator sits last in the sequence, oil mist is introduced downstream of the regulator seat, preventing fouling of the internal pressure control mechanisms.
Weighing 750 g, this compact body is suited for single actuators rather than main plant headers. The unit carries a 25 cc condensate bowl and a 36 cc oil reservoir, requiring frequent attention during continuous operation. No gauge is supplied, but a 1/8in gauge connection allows operators to add instrumentation later for verifying the downstream setpoint.
Airtac GAC F.R.L. Unit GAC20006SN Technical Specifications
| Model | Airtac GAC F.R.L. Unit GAC20006SN |
|---|---|
| Series | GAC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 40 µm |
| Pressure range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Type | Standard |
| Bowl material | PC |
| Drain type | Semi-auto drain + manual drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 750 g |
Specifications follow the official AirTAC GAC catalogue (pages 216-217). Air must not freeze in the unit. No gauge is supplied with this model — the gauge connection on a GAC200 is 1/8" if you add one.
Model Code: Airtac GAC F.R.L. Unit GAC20006SN
| GAC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| (blank) | Drain: Semi-auto drain + manual drain. |
| S | Standard type — 0.15 - 0.9 MPa (20 - 130 psi). This body offers Standard (S) or Lower pressure (L). |
| N | No pressure gauge; 1/8" gauge connection. |
| (blank) | Filtering grade 40 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| (blank) | No reverse-flow valve. |
Constituent units, orderable separately as spares: GAF200-06 filter, GAR200-06 regulator, GAL200-06 lubricator — all three share this body and port.
Size Class & Flow Envelope
- GAC2001/8"-1/4" · 1750 L/min
- GAC3001/4"-1/2" · 3000 L/min
- GAC4003/8"-1/2" · 6000 L/min
- GAC5003/4" · 7000 L/min
- GAC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAC300 (curve to 3000 L/min) |
| Build order | Filter → bracket → regulator → lubricator |
Where the Airtac GAC F.R.L. Unit GAC20006SN Is Used
Small Pneumatic Jigs
Conditions air for compact machining jigs where a single actuator requires steady pressure and fine oil mist lubrication.
Benchtop Assembly Tools
Prepares supply for miniature air-powered screwdrivers and benchtop grinders, protecting internal vanes from moisture.
Lab Automation
Regulates drive air for small solenoid banks and clamping cylinders used in laboratory testing equipment.
Is the Airtac GAC F.R.L. Unit GAC20006SN the Right Air-Prep Unit?
This 1/8in ported unit suits small jigs and individual cylinders, whereas stepping up to the GAC300 body increases the plotted flow envelope from 1750 L/min to 3000 L/min at 0.7 MPa inlet for higher demand. The PC bowl handles standard 1.0 MPa (145 psi) max pressures, while the semi-auto and manual drain pair gives operators flexible condensate management. If the downstream line must remain oil-free, omit the lubricator and choose a filter-regulator instead. Replacement spares share the 200-06 suffix: GAF200-06, GAR200-06 and GAL200-06. Keep in mind the 1.0 MPa maximum supply leaves only 0.1 MPa of headroom above the 0.9 MPa standard ceiling, so inlet pressure must be near maximum to achieve full output.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 750 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a filter-regulator instead of an F.R.L. combination on that branch.
Airtac GAC F.R.L. Unit GAC20006SN FAQ
The standard type operates at 0.15-0.9 MPa (20-130 psi) with a max pressure of 1.0 MPa (145 psi) and a 1.5 MPa (215 psi) proof pressure. Temperature ranges from -5 to 70 C. It features a 25 cc drain bowl, a 36 cc oil bowl, a 40 um element, and weighs 750 g. Use ISO VG 32 lubricant.
The N in the model code indicates no gauge is supplied. The body includes a 1/8in gauge connection, allowing you to install a separate pressure instrument to monitor the 0.15-0.9 MPa range if visual verification of the set pressure is required.
