Airtac SC100 Standard Cylinder SC100X100FA
$119.07
Regular price
$126.57
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SC100X100FA
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enterprise-standard cylinder design optimized for industrial applications;
2. Features proprietary asymmetric bidirectional piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Tie-rod construction with pillar-connected end covers and aluminum tube barrel ensuring enhanced structural reliability;
4. SC Series cylinders feature more compact length versus ISO15552 standard cylinders at equivalent bore sizes;
5. Precision-engineered adjustable cushioning system for smooth stroke termination;
6. Comprehensive range of bore sizes and modular mounting accessories available for flexible configuration;
7. High-temperature resistant sealing materials enable operational range of 0~150°C.
Category: Piston Cylinders | Brand: AirTAC | Series: SC100
Installation guidelines:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
For vertical mounting, use rod-down position to prevent condensate accumulation.
Lubricate through air supply (ISO VG32 turbine oil recommended).
2. Features proprietary asymmetric bidirectional piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Tie-rod construction with pillar-connected end covers and aluminum tube barrel ensuring enhanced structural reliability;
4. SC Series cylinders feature more compact length versus ISO15552 standard cylinders at equivalent bore sizes;
5. Precision-engineered adjustable cushioning system for smooth stroke termination;
6. Comprehensive range of bore sizes and modular mounting accessories available for flexible configuration;
7. High-temperature resistant sealing materials enable operational range of 0~150°C.
Category: Piston Cylinders | Brand: AirTAC | Series: SC100
AirTAC SC100X100FA Standard Cylinder Technical Details
- Model: SC100X100FA
- Type: ISO 15552 compliant double-acting cylinder
- Bore size: 100 mm
- Stroke: 100 mm (±0.5mm tolerance)
- Operating pressure: 0.05-1.0 MPa (7-145 PSI)
- Temperature range: -20℃ to 80℃ (non-freezing)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G3/8 (BSPP thread)
- Piston rod thread: M20×1.5 (external)
- Material: Aluminum alloy barrel, hardened steel rod
- Seal material: NBR (standard), optional Fluorocarbon for high temp
- Protection rating: IP65 (rod extended)
- Lubrication: Pre-lubricated (relubrication interval: 2000km)
- Weight: 7.8 kg (without accessories)
- Dimensions: 300mm(L) × 120mm(W) × 120mm(H)
High-force industrial cylinder with corrosion-resistant anodized surface treatment. Features wear-resistant guide rings and integrated magnet slot for position sensing. The FA suffix indicates front flange mounting (ISO 15552/NFPa pattern) with 4×M12 mounting holes on 125mm square pattern.
Industrial Applications:
- Automotive production line clamping fixtures
- Plastic injection molding machine ejectors
- Steel mill material handling systems
- Paper processing equipment actuators
- Packaging machine pusher mechanisms
Installation guidelines:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
For vertical mounting, use rod-down position to prevent condensate accumulation.
Lubricate through air supply (ISO VG32 turbine oil recommended).
Dynamic specs:
Max piston speed: 500 mm/s (with cushioning),
Theoretical force output: 785N @0.8MPa (extend), 706N @0.8MPa (retract),
Minimum start pressure: 0.08 MPa
| Property | Property Value |
|---|---|
| sku | SC100X100FA |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
