Airtac 2WH High-Pressure Solenoid Valve 2WH030-08-E
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH030-08-E High-Pressure Solenoid Valve Specifications
- Model: 2WH030-08-E
- Type: 2-position, 3-way normally closed (direct-acting)
- Port size: G1/8 (BSPP thread)
- Operating pressure: 0.1–10 MPa (145–1450 PSI)
- Max pressure surge: 15 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Weight: 300g ±5%
- Dimensions: 80mm(L) × 45mm(W) × 65mm(H)
- Seal material: FKM (Viton®) fluorocarbon rubber
- Temperature range: -10℃ to 120℃ (with FKM seals)
- Flow coefficient (Cv): 0.45
- Response time: ≤15ms (at rated voltage)
- Protection rating: IP67 (dustproof & temporary immersion)
- Electrical connection: DIN43650 Form A
High-pressure industrial solenoid valve featuring forged brass body construction with anti-vibration reinforcement. Designed for aggressive hydraulic and pneumatic systems requiring rapid cycling (up to 500,000 cycles). Includes manual override and surge protection. Requires 10μm filtration with ISO 4406 18/16/13 cleanliness standard.
- Hydraulic pressurization systems in die-casting machines
- CNC machine tool coolant control
- High-pressure steam line isolation
- Test bench pressure regulation (leak testing equipment)
- Construction machinery brake systems
Installation requirements:
Mount in vibration-damped orientation (max 5G shock tolerance).
Use backup power supply for critical systems - power interruption >2s may trigger emergency shutoff.
Annual seal replacement recommended for continuous 24/7 operation.
| Property | Property Value |
|---|---|
| sku | 2WH030-08-E |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC24V |
