Airtac 2WH High-Pressure Solenoid Valve 2WH05010C
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH05010C High-Pressure Solenoid Valve Specifications
- Model: 2WH05010C
- Type: 2-position, 5-port direct-acting (high-pressure series)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.5–16 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Body material: Anodized aluminum alloy (SS316 optional)
- Seal material: Fluorinated rubber (FKM)
- Temperature range: -10℃ to 80℃ (with FKM seals)
- Protection rating: IP67 (dustproof & waterproof)
- Flow coefficient (Cv): 0.52
- Response time: ≤20ms (at 20℃)
- Power consumption: 3.5W (DC24V), 5VA (AC)
- Weight: 850g ±5%
- Dimensions: 98mm(L) × 54mm(W) × 84mm(H)
Industrial-grade high-pressure valve featuring dual-coil heat-resistant design (Class H insulation) and surge protection circuitry. The hardened stainless steel spool ensures 2 million+ cycle durability under 10MPa continuous operation. Requires 10μm filtration and automatic drain installation in high-humidity environments.
- Hydraulic pressurization systems (plastic injection molding machines)
- CNC machine tool clamping mechanisms
- High-pressure gas booster stations
- Offshore platform pneumatic controls
- LNG cryogenic valve actuators
Installation note:
Mount horizontally with arrow aligned to flow direction.
Use copper-based anti-seize compound on threaded ports.
Cycle manually 5× before initial energization. Annual lubrication recommended for high-cycle applications.
| Property | Property Value |
|---|---|
| sku | 2WH05010C |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC 110V |
