Airtac 2WH High-Pressure Solenoid Valve 2WH05010EI
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH05010EI High-Pressure Solenoid Valve Specifications
- Model: 2WH05010EI
- Type: 5-port/3-position closed center (Pilot-operated)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.5–12 MPa (7-174 psi)
- Max pressure: 15 MPa (2175 psi) burst pressure
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤30ms (at 5MPa)
- Flow capacity: 850 L/min (Cv=1.2 at 0.7MPa)
- Weight: 530g ±5% (including coil)
- Dimensions: 120mm(L) × 50mm(W) × 62mm(H)
- Seal material: Fluorocarbon rubber (FKM)
- Temperature range: -10℃ to 150℃ (medium temp)
- Ambient temperature: -5℃ to 50℃
- Power consumption: 3.5W (AC), 4.5W (DC)
- Protection rating: IP67 (coil)/IP65 (valve body)
- Port thread depth: 12mm (minimum engagement)
Industrial-grade high-pressure solenoid valve with triple-coil protection and zero-pressure differential start capability. Features stainless steel plunger and reinforced epoxy encapsulation for shock/vibration resistance. Requires 10μm filtration (ISO 4406 17/15/12 class) and lubricated air (ISO VG32 or equivalent).
- Hydraulic system pressure control units
- CNC machine tool clamping systems
- High-pressure pneumatic pumps (200-300 bar systems)
- Plastic injection molding machines
- Compressed natural gas (CNG) distribution systems
- Pressure testing equipment calibration
Installation note:
Mount with vibration-damping brackets in high-shock environments.
Maintain 20mm clearance around coil for heat dissipation.
Pipe connections must use torque-controlled assembly (max 35N·m for G1/8 port).
| Property | Property Value |
|---|---|
| sku | 2WH05010EI |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC24V |
