Airtac 2WH High-Pressure Solenoid Valve 2WH05010F
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH05010F High-Pressure Solenoid Valve Specifications
- Model: 2WH05010F
- Type: 5/2-way direct-acting solenoid valve (high-pressure series)
- Port size: G1/8 (BSPP thread standard)
- Operating pressure range: 0.5-16 MPa (7-232 psi)
- Max working pressure: 21 MPa (304 psi) intermittent
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 3.8W (DC), 5.5VA (AC)
- Body material: Anodized aluminum alloy (ISO 1.0305)
- Seal material: HNBR (Hydrogenated Nitrile) for high-pressure resistance
- Temperature range: -5℃ to 80℃ (with anti-freeze measures below 0℃)
- Response time: ≤15ms (at 20℃ nominal temperature)
- Flow capacity: CV 0.18 (Kv 0.16) at 0.7MPa
- Protection rating: IP67 (dust-tight & protected against temporary immersion)
- Weight: 450g ±5% (including coil)
- Dimensions: 55mm(L) × 40mm(W) × 85mm(H) (excluding ports)
Engineered for extreme pressure environments, the 2WH05010F features a reinforced piston structure with dual-layer T-seals. Its zero-pressure differential start capability and stainless steel armature tube ensure reliable operation in hydraulic/pneumatic hybrid systems. Requires 10μm filtration with automatic drain.
- High-pressure injection molding machine valve stacks
- Hydraulic system pilot controls (up to 500Bar systems)
- CNC machine tool clamping mechanisms
- Pressure testing equipment for aerospace components
- Industrial punching presses with accumulators
Installation criticals:
Must be mounted with vibration-damping brackets in high-shock environments.
Minimum 15mm clearance required around valve body for heat dissipation.
Lubrication oil viscosity must be ISO VG32 or equivalent.
| Property | Property Value |
|---|---|
| sku | 2WH05010F |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC12V |
