Airtac 2WH High-Pressure Solenoid Valve 2WH05015A
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH05015A High Pressure Solenoid Valve Specifications
- Model: 2WH05015A
- Type: 2-position, 5-port direct-acting solenoid valve
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.5–21 MPa (7–3,045 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 520g ±3% (with coil)
- Dimensions: 100mm(L) × 45mm(W) × 60mm(H)
- Seal material: FKM fluorocarbon rubber
- Temperature range: -10℃ to 120℃ (non-freezing conditions)
- Response time: ≤10ms (at 20℃ nominal pressure)
- Flow coefficient (Cv): 1.8 (at 7 bar)
- Protection rating: IP67 (coil assembly)
- Port thread depth: 13mm (full engagement required)
Heavy-duty solenoid valve engineered for extreme pressure environments, featuring reinforced brass body construction and hardened stainless steel spool. The dual-coil heat dissipation design allows continuous duty cycle operation. Requires ISO 8573-1:2010 Class 3.4.3 compressed air quality (max 5μm particles, -20℃ pressure dew point).
- Hydraulic pressurization systems in die-casting machines
- High-pressure gas chromatography equipment
- CNC punch press clutch/brake controls
- Industrial laser cutting gas flow regulation
- Offshore platform pneumatic safety systems
Installation protocol:
Must be mounted vertically (±15° tolerance) with pressure port (P) oriented downward.
Always install a 40μm filter upstream and perform 5-minute run-in cycle at 50%
rated pressure before full operation.
| Property | Property Value |
|---|---|
| sku | 2WH05015A |
| Port Size | PT 1/2 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC220V |
