Airtac 2WH High-Pressure Solenoid Valve 2WH05015C
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH05015C High-Pressure Solenoid Valve Specifications
- Model: 2WH05015C
- Type: 5-port/3-position closed center (pilot-operated)
- Port size: G1/8 (ISO228 standard)
- Operating pressure range: 0.5–15 MPa (72.5–2175 PSI)
- Maximum flow rate: 750 L/min (Cv=1.3 at 0.7 MPa)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 2.5W (DC), 3.5VA (AC)
- Weight: 320g ±5% (including coil)
- Dimensions: 78mm(L) × 42mm(W) × 64mm(H) (excluding fittings)
- Valve body material: Anodized aluminum alloy (A6063-T5)
- Seal material: Fluorocarbon rubber (FKM) for high-temperature resistance
- Temperature range: -10℃ to 150℃ (medium temperature), -5℃ to 80℃ (ambient)
- Response time: ≤15ms (energize), ≤20ms (de-energize) at rated voltage
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 10mm (minimum engagement)
High-performance pneumatic valve engineered for extreme pressure systems requiring precise directional control. Features multi-chamber sealing technology with hardened stainless steel plunger for 2 million+ cycle durability. Includes surge protection circuitry and shock-resistant epoxy-coated coil. Requires filtered (≤40μm) and lubricated air (ISO VG32 or equivalent).
- Hydraulic-pneumatic hybrid pressurization systems
- CNC machine tool clamping/unloading mechanisms
- High-speed bottle blowing machine air circuits
- Test bench pressure cycling systems (e.g., automotive brake testing)
- Mining equipment pneumatic controls
- Plastic injection molding machine core-pulling units
Installation guidelines:
Mount with vibration-damping gaskets in high-shock environments.
Maintain minimum 15mm clearance around exhaust ports.
For horizontal mounting, orient coil upward to prevent debris accumulation.
Pre-lubricate seals with PAG oil during maintenance.
| Property | Property Value |
|---|---|
| sku | 2WH05015C |
| Port Size | PT 1/2 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC 110V |
