Airtac 2WL High Pressure Solenoid Valve 2WL03006A
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL High Pressure Solenoid Valve 2WL03006A Specifications
- Model: 2WL03006A
- Type: 3-position, 5-way direct-acting (closed center)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.5–16 MPa (72–2320 psi)
- Max pressure capacity: 20 MPa (2900 psi)
- Voltage options: DC12V, DC24V, AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 310g ±5% (with connector)
- Dimensions: 64mm(L) × 45mm(W) × 82mm(H)
- Seal material: FKM fluorocarbon (standard) / HNBR optional
- Temperature range: -10℃ to 80℃ (FKM) / -20℃ to 100℃ (HNBR)
- Power consumption: 2.5W (DC) / 4.5VA (AC)
- Response time: ≤15ms (exhaust to port A)
- Flow coefficient (Cv): 1.8
- Protection rating: IP67 (connector included)
- Electrical connection: DIN43650 Form A (M12 connector optional)
Heavy-duty high-pressure solenoid valve engineered for extreme pneumatic systems. Features stainless steel plunger and hardened brass body with triple-layer chrome plating. Equipped with manual override and position sensing capability. Requires 10μm filtration and oil mist lubrication (ISO VG32 recommended).
- Hydraulic system pilot controls
- Injection molding machine clamp units
- CNC press brake tool changers
- High-pressure tire inflation systems
- Industrial boiler safety venting
- Automated test bench sequencing
Installation guidelines:
Always install pressure relief valve upstream. Maximum allowable
instantaneous current: 3A. Use copper-free aluminum alloy piping
for high-pressure connections. Perform weekly manual cycling
during standby periods.
| Property | Property Value |
|---|---|
| sku | 2WL03006A |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC220V |
