Airtac 2WL High Pressure Solenoid Valve 2WL03006AI
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL High Pressure Solenoid Valve 2WL03006AI Specifications
- Model: 2WL03006AI
- Type: 2-position 3-way normally closed (pilot-operated)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.5–21 MPa (7–3,000 PSI)
- Max pressure capacity: 31.5 MPa burst pressure
- Voltage options: DC12V (±10%), DC24V (±10%)
- Coil insulation class: Class F (155℃)
- Power consumption: 5.5W (DC12V), 6.5W (DC24V)
- Weight: 480g ±2% (including coil)
- Dimensions: 78mm(L) × 40mm(W) × 44mm(H)
- Body material: Stainless steel (SUS304)
- Seal material: Fluororubber (FKM)
- Temperature range: -20℃ to 150℃ (media temp)
- Response time: ≤15ms (at 21MPa)
- Protection rating: IP67 (dustproof & waterproof)
- Vibration resistance: ≤55Hz with 1.5mm amplitude
High-pressure specialist valve with military-grade durability, featuring triple-redundant sealing and anti-vibration coil design. Engineered for extreme pressure systems requiring rapid switching, with 500,000-cycle minimum lifespan under rated conditions. Requires 10μm filtration and ISO VG32 hydraulic oil compatibility.
- Hydraulic press emergency stop systems
- Oil & gas wellhead control panels
- High-pressure waterjet cutting machines
- CNC machine tool hydraulic chucks
- Pressure testing equipment calibration
- Offshore platform blowout preventers
Installation criticals:
Must install pressure relief valve in parallel circuit.
Use copper crush gaskets (included) for port connections.
Maximum allowable mounting angle: 15° from vertical axis.
| Property | Property Value |
|---|---|
| sku | 2WL03006AI |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC220V |
