Airtac 2WL High Pressure Solenoid Valve 2WL03006BI
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL High-Pressure Solenoid Valve 2WL03006BI Technical Details
- Model: 2WL03006BI
- Type: 2-position 5-way direct-acting (high-pressure version)
- Port configuration: PT3/8 (G1/2 optional)
- Operating pressure range: 0.5-21 MPa (72.5-3,046 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (±15%), AC220V (±15%)
- Coil insulation class: Class F (155℃)
- Response time: ≤30ms (at 20℃ nominal pressure)
- Flow capacity: CV 1.8 (Kv 1.56) @7 bar
- Seal material: Fluorinated rubber (FKM) standard (HNBR optional)
- Ambient temperature: -20℃ to +150℃ (non-freezing)
- Protection grade: IP67 (dustproof/water immersion resistant)
- Weight: 520g ±5% (without connectors)
- Dimensions: 78mm(L) × 42mm(W) × 104mm(H) (including ports)
- Port thread depth: 13mm (internal threads)
- Max operating frequency: 5Hz (cyclic duty)
- Power consumption: 2.8W (DC24V), 4.5VA (AC220V)
Heavy-duty solenoid valve engineered for ultra-high pressure systems, featuring reinforced stainless steel plunger and shock-resistant epoxy encapsulation. The 2WL series utilizes dual-coil heat dissipation technology with overcurrent protection, capable of continuous operation in 80% relative humidity environments. Requires ISO 8573-1:2010 Class 3 compressed air quality.
- Hydraulic system pressure regulation in injection molding machines
- CNC press brake clamping mechanisms
- High-pressure gas chromatography equipment
- Offshore platform pneumatic controls
- Automotive brake system testing rigs
- Industrial boiler safety venting systems
Installation requirements:
Must be mounted horizontally with arrow aligned to flow direction.
Use torque-limited wrench (15-20Nm for PT threads, 25-30Nm for metric).
Install pulsation damper if pressure fluctuations exceed ±10% of setpoint.
| Property | Property Value |
|---|---|
| sku | 2WL03006BI |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC24V |
