Airtac 2WL High Pressure Solenoid Valve 2WL03006C
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL03006C High-Pressure Solenoid Valve Specifications
- Model: 2WL03006C
- Type: 2-position 3-way normally closed (direct-acting)
- Port size: G1/8 (BSPP thread)
- Operating pressure range: 0.5–25 MPa (7.25–3,625 PSI)
- Maximum working pressure: 31.5 MPa (4,570 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Power consumption: 3.5W (DC), 5.5VA (AC)
- Response time: ≤15ms (open/close)
- Seal material: Fluororubber (FKM) for high-pressure resistance
- Temperature range: -10℃ to 80℃ (non-freezing)
- Fluid compatibility: Air, inert gases, water-glycol mixtures
- Protection rating: IP67 (dustproof & temporary immersion)
- Electrical connection: DIN43650 Form A with LED indicator
- Weight: 680g (1.5 lbs)
- Dimensions: 90mm(L) × 42mm(W) × 52mm(H) (3.54" × 1.65" × 2.05")
Heavy-duty solenoid valve engineered for ultra-high pressure systems, featuring forged brass body construction with nickel plating. Incorporates pressure-balancing piston design for smooth operation under extreme pressures. Rated for 1 million cycles minimum at 15 MPa. Requires 25μm filtration for optimal performance.
- Hydraulic press emergency stop systems
- CNC machine tool coolant control
- High-pressure water jet cutting equipment
- Industrial gas compression systems
- Test bench pressure regulation
- Offshore drilling equipment controls
Installation guidelines:
Mount in vibration-free environment using supplied bracket (AXF10-M5).
Always install downstream pressure gauge port (M5×0.8 thread) facing upward.
Perform weekly manual override testing in high-cycling applications.
| Property | Property Value |
|---|---|
| sku | 2WL03006C |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC 110V |
