Airtac 2WL High Pressure Solenoid Valve 2WL03006EI
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL03006EI High-Pressure Solenoid Valve Specifications
- Model: 2WL03006EI
- Type: 3-position, 5-way (double solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.5–16 MPa (high-pressure optimized)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 1.2 kg (with coil)
- Dimensions: 76mm(L) × 52mm(W) × 105mm(H)
- Seal material: Fluorocarbon rubber (FKM) + HNBR
- Temperature range: -10℃ to 150℃ (with pulse tolerance to 180℃)
- Power consumption: ≤3.5W (DC)/≤4.5VA (AC)
- Flow capacity: 750 l/min (ANR) @ 0.7MPa
- Response time: ≤15ms (exhaust to full open)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 13mm (full thread engagement)
Heavy-duty high-pressure valve featuring triple-layered sealing system and shock-resistant aluminum alloy body. Designed for aggressive duty cycles with 10 million minimum operations rating. Integrated surge protection circuitry prevents coil burnout. Requires ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content).
- Hydraulic system pilot controls in injection molding machines
- High-pressure gas cutting equipment (300-400PSI systems)
- CNC machine tool clamping mechanisms
- Off-road vehicle pneumatic suspensions
- Natural gas pipeline emergency shut-off systems
Installation protocol:
Always install downstream filter regulator (40μm minimum).
For vertical mounting, use anti-vibration bracket (AVB-2WL accessory recommended).
Allow 15-minute run-in period at 50% pressure before full operation.
| Property | Property Value |
|---|---|
| sku | 2WL03006EI |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC24V |
