Airtac 2WL High Pressure Solenoid Valve 2WL03006FI
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL High Pressure Solenoid Valve 2WL03006FI Specifications
- Model: 2WL03006FI
- Type: 2-position 3-way normally closed (direct-acting)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure: 0.5–21 MPa (72.5–3046 PSI)
- Max pressure resistance: 31.5 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 4.5W (DC24V), 5.5VA (AC)
- Flow coefficient (Cv): 2.0
- Response time: ≤15ms (at 21MPa)
- Weight: 780g ±3%
- Dimensions: 120mm(L) × 65mm(W) × 72mm(H)
- Valve body material: Anodized aluminum alloy (ISO AlSi10Mg)
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE backup
- Temperature range: -40℃ to 150℃ (with intermittent peak 180℃)
- Protection rating: IP67 (military-grade dust/water resistance)
- Port connection: SAE J1926-1 standard
- Cycle life: ≥10 million operations (at 15MPa)
Industrial-grade high pressure solenoid valve engineered for extreme hydraulic/pneumatic systems. Features triple-layer sealing architecture with pressure-adaptive spool design, capable of handling high-viscosity fluids (ISO VG 68) and aggressive media when equipped with optional FKM seals. The forged aluminum body incorporates anti-vibration ribs and thermal dissipation channels.
- Hydraulic press clutch/brake systems
- CNC machine tool coolant control
- High-pressure gas boosters (500-3000PSI)
- Offshore drilling equipment actuators
- Test bench pressure regulation systems
- Die-casting machine injection control
Installation protocol:
Requires pressure balancing during startup - gradually increase system pressure
from 0.5MPa to operational level over 30sec. Maintain 15cm clearance below valve
for heat dissipation. Use Loctite 577 thread sealant (not Teflon tape) for port connections.
| Property | Property Value |
|---|---|
| sku | 2WL03006FI |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC12V |
