Airtac 2WL High Pressure Solenoid Valve 2WL03008A
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL03008A High-Pressure Solenoid Valve Specifications
- Model: 2WL03008A
- Type: 5/2-way double solenoid (direct-acting)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure: 0.5-21 MPa (7-3,000 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow rate: 1,200 L/min (ANR)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Weight: 1.25 kg (including connectors)
- Dimensions: 120mm(L) × 70mm(W) × 85mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE coating
- Temperature range: -30℃ to 150℃ (media), -15℃ to 60℃ (ambient)
- Power consumption: 5.5W (DC), 7VA (AC)
- Protection rating: IP67 (connector type: DIN43650 Form C)
- Port thread depth: 15mm (minimum engagement)
High-flow industrial solenoid valve engineered for extreme pressure systems, featuring dual-coil latching design for energy efficiency. The hardened stainless steel spool and triple-layer sealing ensure leak-free operation in vibration-intensive environments. Compatible with compressed air, inert gases, and light hydraulic oils (ISO VG32 or lower).
- Injection molding machine clamp mechanisms
- Hydraulic press power unit control
- High-pressure pneumatic testing equipment
- Steel mill cylinder sequencing systems
- Off-road vehicle braking circuits
Installation note:
Always install downstream filter (≤25μm) and lubricator when used with pneumatic systems.
For hydraulic applications, maintain fluid cleanliness to NAS 9 class.
Allow 30mm lateral clearance for heat dissipation during continuous operation.
| Property | Property Value |
|---|---|
| sku | 2WL03008A |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC220V |
