Airtac 2WL High Pressure Solenoid Valve 2WL03008AI
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL High Pressure Solenoid Valve 2WL03008AI Specifications
- Model: 2WL03008AI
- Type: 5/2-way direct-acting with high pressure tolerance
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.3–16 MPa (43–2,320 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz), DC12V
- Weight: ~450g (including coil and connectors)
- Dimensions: 85mm(L) × 62mm(W) × 112mm(H)
- Seal material: FKM (Fluorocarbon Rubber) for high temp/pressure
- Temperature range: -10℃ to 120℃ (non-freezing)
- Power consumption: 2.5W (DC) / 5VA (AC)
- Response time: ≤15ms (at rated voltage)
- Port thread depth: 12mm (minimum engagement)
- Flow coefficient (Cv): 1.8 (at 7 bar)
- Protection rating: IP67 (dustproof & temporary immersion)
Industrial-grade high-pressure solenoid valve featuring forged brass body with hard-anodized aluminum sleeve. Designed for aggressive duty cycles in hydraulic/pneumatic hybrid systems. Incorporates dual-coil heat dissipation technology and surge protection circuitry. Requires 5μm filtration (ISO 4406 16/14/11 class recommended).
- Hydraulic pressurization systems in plastic injection molding
- High-pressure gas control in industrial CNC machinery
- Automotive testing rigs requiring 10MPa+ operation
- Foundry equipment for molten metal pneumatic controls
- Off-road vehicle central lubrication systems
Installation criticals:
(1) Port alignment must be ±1° tolerance to prevent thread galling
(2) Always install downstream moisture separator
(3) Coil orientation must be within 15° of vertical position
(4) Allow 15mm radial clearance for thermal expansion
| Property | Property Value |
|---|---|
| sku | 2WL03008AI |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC220V |
