Airtac 2WL High Pressure Solenoid Valve 2WL03008B
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL03008B High-Pressure Solenoid Valve Technical Details
- Model: 2WL03008B
- Type: Direct-acting 2-position 3-way (2WL series)
- Port configuration: 3/2-way normally closed
- Port size: PT1/8" (NPT1/8" optional)
- Operating pressure range: 0.5-21 MPa (72.5-3,046 PSI)
- Proof pressure: 31.5 MPa (4,568 PSI)
- Voltage tolerance: ±10%
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 5.5W (DC24V), 6.5VA (AC)
- Max operating frequency: 10 Hz
- Flow capacity: Cv=0.15 (Kv=0.13)
- Response time: ≤15ms (at 20℃, rated voltage)
- Body material: Anodized aluminum alloy (hard coat)
- Seal material: FKM (Fluorocarbon rubber)
- Ambient temperature: -20℃ to 150℃ (no freezing)
- Medium temperature: -20℃ to 80℃
- Protection class: IP65 (dust-tight & water jet resistant)
- Weight: 480g ±2% (without connector)
- Dimensions: 70mm(L) × 54mm(W) × 76mm(H)
- Port thread depth: 10mm (full engagement required)
Engineered for extreme pressure environments, the 2WL03008B features forged brass core components and triple-layer epoxy coating for corrosion resistance. Its dual-chamber design isolates electrical components from media flow, enabling stable operation in high-vibration industrial settings. Requires 10μm filtration and oil mist lubrication (ISO VG32 recommended).
- Hydraulic system pressure regulation (die-casting machines)
- CNC machine tool coolant control
- High-pressure gas chromatography systems
- Industrial boiler safety shut-off systems
- Pressure vessel testing equipment
- Offshore drilling platform pneumatic controls
Critical installation notes:
- Mount with flow arrow aligned to system direction
- Install pressure relief valve upstream
- Use torque wrench (15-20N·m for port connections)
- Allow 30-minute burn-in at 50% pressure before full operation
| Property | Property Value |
|---|---|
| sku | 2WL03008B |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC24V |
