Airtac 2WL High Pressure Solenoid Valve 2WL03008BI
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL High Pressure Solenoid Valve 2WL03008BI Technical Details
- Model: 2WL03008BI
- Type: 2-position 3-way normally closed (direct-acting high pressure)
- Port size: G1/8 (NPT1/4 optional)
- Operating pressure: 0.5-21 MPa (72.5-3,046 PSI)
- Voltage options: DC24V (±10%), AC110V 50/60Hz, AC220V 50/60Hz
- Response time: ≤15ms (open), ≤20ms (close)
- Flow capacity: Cv 0.35 / Kv 0.3 (at 7 bar)
- Seal material: FKM fluorocarbon rubber
- Temperature range: -10℃ to 150℃ (non-freezing)
- Weight: 850g ±5% (without connectors)
- Dimensions: 80mm(L) × 50mm(W) × 60mm(H)
- Protection rating: IP67 (dustproof & temporary immersion)
- Hysteresis: ≤0.5% F.S.
- Proof pressure: 31.5 MPa (1.5× rated pressure)
Heavy-duty solenoid valve engineered for extreme pressure environments, featuring forged brass body with triple-layer chrome plating. The direct-acting design ensures reliable operation without minimum pressure requirements. Includes manual override and surge protection circuitry. Compatible with hydraulic oils (ISO VG32-68) and compressed air (lubricated/non-lubricated).
- Hydraulic pressurization systems
- Oil & gas wellhead control panels
- High-pressure water jet cutting machines
- CNC hydraulic tool changers
- Pressure testing equipment (leak detection systems)
Installation requirements:
Always perform pressure decay test before commissioning. Use backup seals when handling aggressive media.
Mount with vibration-damping brackets if ambient vibration exceeds 5G. Pipe connections must be torque-limited
to 25-30 N·m using anti-seize compound.
| Property | Property Value |
|---|---|
| sku | 2WL03008BI |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC24V |
