Airtac 2WL High Pressure Solenoid Valve 2WL03008C
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL High Pressure Solenoid Valve 2WL03008C Technical Details
- Model: 2WL03008C
- Type: 5/2-way monostable (direct-acting)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.5–25 MPa (725–3,626 psi)
- Maximum pressure: 35 MPa (5,076 psi) burst resistance
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Weight: 1.35 kg (2.98 lbs)
- Dimensions: 152mm(L) × 55mm(W) × 62mm(H)
- Body material: Anodized aluminum alloy (A6063-T5)
- Seal components: HNBR with PTFE reinforcement
- Temperature tolerance: -40℃ to 120℃ (with derating above 80℃)
- Power consumption: 4.8W (DC), 6VA (AC)
- Response time: ≤15ms (at 20℃ nominal pressure)
- Flow coefficient (Cv): 1.8 (at 7 bar)
- Protection class: IP67 (dustproof & temporary immersion)
- Port thread depth: 12mm (minimum engagement)
Heavy-duty high-pressure solenoid valve engineered for extreme industrial environments. Features triple-layer sealing architecture with impact-resistant construction and anti-vibration coil design. The hardened stainless steel plunger system ensures 500,000+ cycle durability under 25MPa continuous operation. Requires 10μm filtration and automatic drain installation in vertical position (±15° tolerance).
- Hydraulic pressurization systems in die casting machines
- CNC punch press clutch/brake control
- High-pressure water jet cutting equipment (60,000+ PSI systems)
- Offshore oil rig pneumatic controls
- Mining drill rig air hammer circuits
- Railway braking system test benches
Critical note:
Mandatory 500-hour run-in period with pressure increments (start at 50% rated pressure).
Use only ISO VG32 or equivalent hydraulic fluid. Copper-free alloys required in downstream piping.
| Property | Property Value |
|---|---|
| sku | 2WL03008C |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC 110V |
