Airtac 2WL High Pressure Solenoid Valve 2WL03008CI
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL High Pressure Solenoid Valve 2WL03008CI Technical Details
- Model: 2WL03008CI
- Type: 5/3-way closed center (high pressure direct-acting)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure: 0.5–21 MPa (72.5–3,046 PSI)
- Voltage options: DC24V (±10%), AC110V/220V (±15% 50/60Hz)
- Weight: 520g ±5% (with connector)
- Dimensions: 83mm(L) × 54mm(W) × 62mm(H)
- Seal material: Fluororubber (FKM) with stainless steel plunger
- Temperature range: -10℃ to 150℃ (non-freezing conditions)
- Power consumption: 4.5W (AC), 3.6W (DC)
- Flow rate: 1,200 Nl/min (ANR at 0.7MPa)
- Response time: ≤15ms (energized), ≤20ms (de-energized)
- Protection rating: IP67 (dustproof & waterproof)
- Service life: ≥10 million cycles (clean air conditions)
Heavy-duty solenoid valve engineered for ultra-high pressure pneumatic systems, featuring dual-coil heat dissipation design and shock-resistant construction. Requires 25μm filtered compressed air with oil mist lubrication (ISO 8573-1 class 3). Compatible with inert gases when using optional seals.
- Hydraulic press emergency release systems
- CNC machine tool clamping mechanisms
- High-pressure tire inflation stations
- Railway braking system simulation rigs
- Industrial laser cutting gas control
- Offshore platform pneumatic tools
Installation guidelines:
Mount horizontally with arrow direction matching airflow.
Allow 50mm clearance above coil for heat dissipation.
Pre-charge system to ≥0.3MPa before initial activation.
Use locknuts with 25-30N·m torque for port connections.
| Property | Property Value |
|---|---|
| sku | 2WL03008CI |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC 110V |
