Airtac 2WL High Pressure Solenoid Valve 2WL03008F
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL03008F High Pressure Solenoid Valve Specifications
- Model: 2WL03008F
- Type: 5/3-way double solenoid operated (closed center)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.5–16 MPa (72–2320 psi)
- Max pressure surge resistance: 24 MPa
- Voltage options: DC12V(±10%), DC24V(±10%), AC110V(±10% 50/60Hz), AC220V(±10% 50/60Hz)
- Coil power: 1.8W (DC), 2.8VA (AC)
- Response time: ≤15ms (excitation), ≤20ms (reset)
- Seal material: Fluororubber (FKM) standard (NBR optional)
- Temperature range: -10℃ to 80℃ (14°F to 176°F)
- Viscosity range: ≤50 cSt
- Flow rate: 1800 NL/min (ANR)
- Weight: 1.2 kg (2.65 lbs)
- Dimensions: 135mm(L) × 55mm(W) × 62mm(H) (5.31"×2.17"×2.44")
- Protection rating: IP67 (connector included)
- Port thread depth: 12mm (minimum engagement)
Heavy-duty high-pressure valve with stainless steel plunger and anti-vibration structure. Features dual manual override buttons with position indicators. Designed for industrial hydraulic/pneumatic hybrid systems requiring extreme pressure stability. Requires ISO 4401 mounting interface.
- Hydraulic press clutch/brake control systems
- High-pressure gas booster circuits
- Injection molding machine hydraulic units
- CNC machine tool hydraulic chucks
- Off-road vehicle suspension systems
Installation criticals:
Use Loctite 545 thread sealant (not Teflon tape). Maximum allowable
torque 30N·m. Requires 20-30 micron filtration. Perform pressure
cycling 3-5 times before full operation.
| Property | Property Value |
|---|---|
| sku | 2WL03008F |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC12V |
