Airtac 2WL High Pressure Solenoid Valve 2WL03008FI
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL High Pressure Solenoid Valve 2WL03008FI Technical Details
- Model: 2WL03008FI
- Type: 2-position 3-way normally closed (direct-acting)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure: 0.5–16 MPa (72–2320 psi)
- Max pressure capacity: 20 MPa (burst pressure)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Coil insulation class: Class F (155℃)
- Power consumption: 3.5W (DC), 5.5VA (AC)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: FKM fluorocarbon rubber
- Body material: Anodized aluminum alloy (valve), Stainless steel (core tube)
- Temperature range: -20℃ to 120℃ (medium), -5℃ to 80℃ (ambient)
- Protection rating: IP67 (coil), IP65 (valve body)
- Vibration resistance: ≤55Hz with 1.5mm amplitude
- Weight: 520g ±5% (without connector)
- Dimensions: 102mm(L) × 54mm(W) × 83mm(H)
Industrial-grade high-pressure solenoid valve engineered for extreme pneumatic/hydraulic systems. Features triple-sealed coil encapsulation and reinforced flow path design capable of handling viscous media. The hardened stainless steel plunger ensures 500,000+ cycle durability under 10MPa continuous operation. Requires 10μm filtration with oil mist lubrication recommended.
- Hydraulic pressurization systems in die casting machines
- High-pressure gas boosters for leak testing equipment
- CNC machine tool clamping mechanisms
- Injection molding machine hydraulic circuits
- Industrial boiler safety venting controls
Installation criticals:
Must install pressure relief valve upstream. Maintain 15° maximum deviation from vertical axis during mounting.
Apply thread sealant on male ports (PTFE tape prohibited). Perform 3-minute low-pressure run-in before full operation.
| Property | Property Value |
|---|---|
| sku | 2WL03008FI |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC12V |
