Airtac 2WL High Pressure Solenoid Valve 2WL05010A
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL05010A High-Pressure Solenoid Valve Specifications
- Model: 2WL05010A
- Type: 5/2-way monostable (direct-acting)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.5–21 MPa (7–3,045 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±15%), AC220V (±15%)
- Weight: 580g ±2% (with connector)
- Dimensions: 122mm(L) × 52mm(W) × 68mm(H)
- Seal material: FKM (Fluorocarbon Rubber) standard, EPDM/NBR optional
- Temperature range: -10℃ to 80℃ (non-freezing)
- Power consumption: 4.5W (DC24V), 5.2VA (AC220V)
- Flow capacity: 1,200 NL/min (ANR, at 0.5MPa)
- Response time: ≤25ms (exhaust to full open)
- Protection rating: IP67 (dust/water resistant)
- Port thread tolerance: ISO 228-1 G-series
High-flow industrial solenoid valve engineered for extreme pressure systems, featuring hardened stainless steel plunger and reinforced epoxy coil housing. Optimized for hydraulic/pneumatic hybrid applications with 5-port configuration allowing independent control of dual actuators. Includes manual override and LED status indicator. Requires 25μm filtration with oil mist lubrication (ISO 8573-1 Class 4).
- Hydraulic press clutch/brake systems
- CNC machine tool clamping mechanisms
- High-pressure tire inflation systems
- Plastic injection molding machines
- Test bench pressure regulation (air/neutral gases)
Installation note:
Mount with vibration-damping gaskets in high-shock environments.
Maintain ≥15mm clearance from heat sources. Lubricate sliding parts
with ISO VG32 hydraulic oil during maintenance.
| Property | Property Value |
|---|---|
| sku | 2WL05010A |
| Port Size | PT3/8 |
| Flow Aperture | 7mm |
| Coil Voltage | AC220V |
