Airtac 2WL High Pressure Solenoid Valve 2WL05010AI
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL05010AI High-Pressure Solenoid Valve Specifications
- Model: 2WL05010AI
- Type: 5/2-way monostable (direct-acting)
- Port size: PT1/2 (G1/2 optional)
- Operating pressure: 0.5–25 MPa (high-pressure variant)
- Voltage options: DC12V, DC24V, AC110V/50-60Hz, AC220V/50-60Hz
- Weight: 2.3 kg ±5%
- Dimensions: 162mm(L) × 58mm(W) × 65mm(H)
- Body material: Anodized aluminum alloy (hard coating)
- Seal material: Fluororubber (FKM) standard, HNBR optional
- Temperature range: -10℃ to 150℃ (with FKM seals)
- Flow coefficient (Cv): 4.2
- Response time: ≤15ms (at 20MPa)
- Protection rating: IP67 (submersible design)
- Port thread depth: 15mm (ISO 1179-1 compliant)
Heavy-duty solenoid valve engineered for ultra-high pressure systems, featuring rapid switching capability and reinforced internal structure. The dual-coil heat dissipation design ensures stable operation under continuous cycling. Compatible with hydraulic oils (HFA/HFB/HFC) and compressed air. Includes manual override button for emergency control.
- Hydraulic pressurization systems in die-casting machines
- High-pressure water jet cutting equipment
- CNC machine tool clamping mechanisms
- Offshore platform pneumatic controls
- Automotive brake testing rigs
Installation requirements:
Requires vibration-damping mounting brackets for pressures above 15MPa.
Use 25μm filtration for hydraulic applications. Lubrication-free operation
but demands monthly manual cycling during standby periods.
Avoid horizontal installation - arrow marking must face upward ±15°.
| Property | Property Value |
|---|---|
| sku | 2WL05010AI |
| Port Size | PT3/8 |
| Flow Aperture | 7mm |
| Coil Voltage | AC220V |
