Airtac 2WL High Pressure Solenoid Valve 2WL05010B
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL05010B High-Pressure Solenoid Valve Specifications
- Model: 2WL05010B
- Type: 2-position, 5-port direct-acting (high-pressure variant)
- Port size: PT1/4 (G1/4 thread standard)
- Operating pressure: 0.5–16 MPa (72–2320 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 520g ±5% (with connector)
- Dimensions: 62mm(L) × 48mm(W) × 78mm(H) (excluding fittings)
- Seal material: Fluorinated rubber (FKM) for high-pressure resistance
- Temperature range: -10℃ to 150℃ (medium temperature)
- Flow capacity: 1200 NL/min (ANR, at 0.5MPa pressure difference)
- Protection rating: IP67 (dustproof & temporary immersion)
- Response time: ≤15ms (at rated voltage)
- Mounting orientation: Any (360° rotatable manifold)
Industrial-grade high-pressure solenoid valve engineered for extreme pneumatic systems, featuring enhanced structural integrity with forged brass body and hardened stainless steel core components. The optimized flow path design reduces pressure drop by 18% compared to standard models. Requires 25μm filtration and oil mist lubrication (ISO 8573-1 class 4).
- Hydraulic-pneumatic hybrid control systems
- CNC machine tool clamping mechanisms
- High-pressure gas booster circuits
- Plastic injection molding machines
- Automotive brake system test benches
- Industrial laser cutting gas control
Installation note:
Apply thread sealant (LOCTITE 577 recommended) on port connections.
For continuous operation above 10MPa, install pulsation dampeners upstream.
Minimum 20mm clearance required for heat dissipation during cyclic operation.
| Property | Property Value |
|---|---|
| sku | 2WL05010B |
| Port Size | PT3/8 |
| Flow Aperture | 7mm |
| Coil Voltage | DC24V |
