Airtac 2WL High Pressure Solenoid Valve 2WL05010CI
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL05010CI High-Pressure Solenoid Valve Specifications
- Model: 2WL05010CI
- Type: 5/2-way monostable (direct-acting high-pressure design)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.5–21 MPa (7–3,045 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±15%), AC220V (±15%)
- Weight: 0.85 kg (1.87 lbs)
- Dimensions: 130mm(L) × 52mm(W) × 95mm(H)
- Valve body material: Anodized aluminum alloy (ISO-AlSi10Mg)
- Seal material: Fluororubber (FKM) standard (HNBR optional)
- Temperature range: -20℃ to 150℃ (with FKM seals)
- Flow coefficient (Cv): 2.4 at 7 bar
- Response time: ≤25ms (energize), ≤35ms (de-energize)
- Power consumption: 4.5W (DC24V), 5.5VA (AC220V)
- Protection rating: IP67 (dustproof & waterproof)
- Port thread depth: 12mm (minimum engagement)
High-torque solenoid valve engineered for extreme pressure environments, featuring triple-redundant sealing and anti-vibration coil design. The 2WL series incorporates pressure-balancing spool technology that enables stable switching under fluctuating loads. Requires ISO 8573-1:2010 Class 3 compressed air (max 50mg/m³ oil content).
- Hydraulic system pilot controls
- CNC machine tool clamping mechanisms
- High-pressure gas chromatography systems
- Plastic injection molding machines
- Subsea equipment pneumatic controls
- Railway braking system test benches
Installation protocol:
Mount with vibration-damping brackets in high-shock environments.
Apply 20-30Nm torque during port connection.
Perform 500-cycle burn-in test before critical operations.
Maintenance alert:
Replace desiccant in upstream filters every 800 operating hours.
Lubricate spool shaft with PAG oil (ISO VG 32) quarterly.
| Property | Property Value |
|---|---|
| sku | 2WL05010CI |
| Port Size | PT3/8 |
| Flow Aperture | 7mm |
| Coil Voltage | AC 110V |
