Airtac 3V-F Base 3V100M11F
$26.48
Regular price
$33.98
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
3V100M11F
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Enables integration of same-series directional control valves into modular valve groups, achieving space-saving design and cost-effective solutions;
2、Features centralized inlet/exhaust ports and unified wiring configuration, which simplifies troubleshooting during system failures;
3、Offers flexible configuration and high expandability, allowing arbitrary combination or modular expansion of connected directional control valves;
Category: Solenoid Valve Bases | Brand: AIRTAC | Series: 3V-F
Installation note:
Apply thread sealant (LOCTITE 5452 recommended) on manifold screws.
Torque mounting bolts to 1.2-1.5 N·m using cross pattern tightening sequence.
Ensure base surface flatness ≤0.05mm before multi-unit stacking.
2、Features centralized inlet/exhaust ports and unified wiring configuration, which simplifies troubleshooting during system failures;
3、Offers flexible configuration and high expandability, allowing arbitrary combination or modular expansion of connected directional control valves;
Category: Solenoid Valve Bases | Brand: AIRTAC | Series: 3V-F
AirTAC 3V100M11F Valve Base Specifications
- Model: 3V100M11F (3V-F Series)
- Type: Modular base for 3/2-way solenoid valves
- Mounting Standard: ISO 15407-1 (compatible with multiple brands)
- Port Thread: G1/8 (BSPP) with dual sealing grooves
- Material: Anodized aluminum alloy (AL6063-T5)
- Surface Hardness: HV 0.2≥12° (hard anodized finish)
- Weight: 205g ±5g
- Dimensions: 52mm(L) × 34mm(W) × 22.5mm(H)
- Mounting Hole Spacing: 25mm × 25mm (4×M5 threaded holes)
- Seal Compatibility: NBR/Viton optional
- Max Operating Pressure: 1.0 MPa
- Temperature Range: -20℃ to 80℃ (with standard seals)
- Flow Capacity: 750 NL/min (at 0.5 MPa)
- Compatible Valves: 3V1/3V2/3V3 series solenoid valves
Precision-machined manifold base featuring multi-chamber flow design for reduced pressure drop. Includes integrated silencer ports and auto-bleed function for rapid valve switching. The diamond-cut sealing surfaces ensure leak-free connections even under vibration conditions.
Typical Applications:
- Modular pneumatic control stations in assembly lines
- Multi-valve manifolds for packaging machinery
- Robotic tool changer interfaces
- CNC machine tool clamping systems
- Semiconductor handling equipment
Installation note:
Apply thread sealant (LOCTITE 5452 recommended) on manifold screws.
Torque mounting bolts to 1.2-1.5 N·m using cross pattern tightening sequence.
Ensure base surface flatness ≤0.05mm before multi-unit stacking.
