Airtac 3V-F Base 3V100M4F
The AirTAC Airtac 3V-F Base 3V100M4F is a genuine 3V-F manifold base manifold base for 4 stations on one shared air supply. A base is a machined block: it carries no coil and no solenoid, so the valves that sit on it are ordered separately.
- Valve type3/2-way (3-port, 2-position)
- Stations4
- Series3V-F manifold base
About the Airtac 3V-F Base 3V100M4F
With four stations, the 3V100M4F lets four AirTAC 3V1 series 3/2 valves share one machined block and one air supply. Every valve still switches its own outlet and exhaust independently - the base only feeds them; it does not merge their functions.
It is a genuine AirTAC component. Around it, the 3V1 valve family spans NC and NO states, all five catalogue coil voltages and DIN plug or flying-lead entries, and bases from 1F up to 20F. Datasheet figures such as flow and coil power are not published on this page - send an RFQ and we will confirm them for your application.
Airtac 3V-F Base 3V100M4F Technical Specifications
| Model | Airtac 3V-F Base 3V100M4F |
|---|---|
| Series | 3V-F manifold base |
| Item form | Manifold base (no coil, no solenoid, no initial state) |
| Stations | 4 |
| Port size | Confirm from the datasheet — ask us |
| Thread | PT |
| Operating pressure | Confirm from the datasheet — ask us |
|---|---|
| Flow coefficient | Confirm from the datasheet — ask us |
| Temperature | Confirm from the datasheet — ask us |
| Protection | Confirm from the datasheet — ask us |
Model Code: Airtac 3V-F Base 3V100M4F
| 3V-F manifold base | Body. |
|---|---|
| 4F | 4 stations in one assembly. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V-F Base 3V100M4F Is Used
Multi-station test rig
A leak-test or assembly bench running four separate clamp-and-vent functions switches them all from one manifold fed by a single regulator.
Conveyor gate control
Four pneumatic gates or pushers along a conveyor line are driven by single-acting cylinders, each with its own 3/2 valve on the shared base.
Workshop fixture build
A bespoke clamping fixture with four swing clamps keeps its valve wiring and tubing in one place, making later changes straightforward.
Is the Airtac 3V-F Base 3V100M4F the Right Part?
A four-station base is a natural fit for a machine with four spring-return actuators or four on/off air functions fed from a single point. Pick each valve separately: NC for no air at the outlet until energised, NO to vent only when energised, the port step from M5 to 3/8in to match the actuator, and a coil voltage that must match your panel supply - it cannot be changed by rewiring. We will check valve sizing against your actuators from the datasheet on request. If published flow numbers are needed today, look at the documented 3V2 (1/8in, 1/4in) and 3V3 (1/4in) bodies; for double-acting cylinders, the AirTAC 4V series is the right family.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V-F Base 3V100M4F FAQ
Yes - pressure range, flow and coil power all come from the datasheet, which we confirm on request. When published figures are needed immediately, the AirTAC 3V2 and 3V3 valve bodies carry documented flow and coil-power data.
It is a machined block that mounts several 3/2 valves on one shared air supply, so you run one feed tube and one wiring path instead of four. Valves are ordered separately, and the family carries station counts from 1F to 20F.
