Airtac 3V-F Base 3V100M9F
The AirTAC Airtac 3V-F Base 3V100M9F is a genuine 3V-F manifold base manifold base for 9 stations on one shared air supply. A base is a machined block: it carries no coil and no solenoid, so the valves that sit on it are ordered separately.
- Valve type3/2-way (3-port, 2-position)
- Stations9
- Series3V-F manifold base
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 3V-F Base 3V100M9F
The 3V100M9F is a machined manifold base with nine stations, made to carry AirTAC 3/2 solenoid valves from the 3V1x0 family on a single shared air feed. It carries no coil itself, so there is no voltage, no electrical state and no power draw at the base - those belong to the valves you mount on it. With one common supply, one mounting surface and one wiring route for nine valves, the base turns nine separate installs into one tidy block.
We stock the 3V100M9F as a genuine AirTAC part, and the 3/2 valves that fill its stations are ordered separately, so you can mix normally closed and normally open bodies on the same block. PT thread is the standard on this family, with G and NPT available as order options. Datasheet figures for the family are not in our hands, so send us your list and we will confirm the details from the datasheet.
Airtac 3V-F Base 3V100M9F Technical Specifications
| Model | Airtac 3V-F Base 3V100M9F |
|---|---|
| Series | 3V-F manifold base |
| Item form | Manifold base (no coil, no solenoid, no initial state) |
| Stations | 9 |
| Port size | Confirm from the datasheet — ask us |
| Thread | PT |
| Operating pressure | Confirm from the datasheet — ask us |
|---|---|
| Flow coefficient | Confirm from the datasheet — ask us |
| Temperature | Confirm from the datasheet — ask us |
| Protection | Confirm from the datasheet — ask us |
Model Code: Airtac 3V-F Base 3V100M9F
| 3V-F manifold base | Body. |
|---|---|
| 9F | 9 stations in one assembly. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V-F Base 3V100M9F Is Used
Packaging machine station bank
A cartoning or wrapping line that fires several single-acting air cylinders - one per sealing, folding or ejection station - can mount all nine 3/2 valves on one 3V100M9F block and feed the whole bank from a single air line.
Assembly fixture clamping array
A workholding fixture with multiple spring-return clamps can drive each clamp from its own 3/2 valve on the shared manifold, so a failed clamp valve is swapped out on the block without disturbing neighbouring air piping.
Bottling line blow-off stations
A filling or bottling line that clears dust or droplets from containers at several points can run one on/off air valve per station from a single manifold, keeping the air supply and wiring to the rinse zone in one run.
Is the Airtac 3V-F Base 3V100M9F the Right Part?
Choose this 9-station base when several 3/2 valves sit close together on one machine and you want a single air feed instead of nine individual supplies and nine scattered mountings. Consolidating the valves on one block shortens the piping run, groups the wiring into one loom and makes fault-finding a matter of walking down the stations rather than hunting around the frame.
The base itself makes no choices about function - those come from the valves you order for it. Pick normally closed bodies where the outlet must stay vented until energised, normally open where it must stay fed, and match each coil voltage to the panel supply, since a coil cannot be changed by rewiring. If sizing matters, note that published flow figures for this family are not available to us, so ask us to confirm suitability against your actuators before ordering. Where a fully specified 3-port valve is needed today, the documented AirTAC 3V2 (1/8in and 1/4in) and 3V3 (1/4in) direct-acting bodies carry published flow and coil-power data, and a double-acting cylinder needs a 5-port valve from the AirTAC 4V series instead.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V-F Base 3V100M9F FAQ
This base is defined by its station count and thread rather than by figures of its own, and we do not hold a published datasheet for the 3V1x0 family it serves. Tell us which pressure, flow or coil-power questions you have and we will confirm them from the datasheet. If you need published numbers in hand today, the AirTAC 3V2 and 3V3 bodies carry documented flow and coil-power figures.
The 3V100M9F is only the manifold block - order a 3/2 valve for every station you plan to use, choosing normally closed or normally open per function and the coil voltage that matches your panel. Note that a 3/2 valve cannot drive a double-acting cylinder, which needs two opposed air paths; for that job use a 5-port valve from the AirTAC 4V series and keep the 3/2 stations for single-acting and blow-off duties.
