Airtac 3V-F Base 3V200M1F
2、Features centralized inlet/exhaust ports and unified wiring configuration, which simplifies troubleshooting during system failures;
3、Offers flexible configuration and high expandability, allowing arbitrary combination or modular expansion of connected directional control valves;
Category: Solenoid Valve Bases | Brand: AIRTAC | Series: 3V-F
AirTAC 3V200M1F Valve Base Specifications
- Model: 3V200M1F (3V-F Series Modular Base)
- Type: 5-port 2-position base for solenoid valve assembly
- Port configuration: P (pressure), A/B (actuator ports), R/S (exhausts)
- Thread size: 1/4" BSPP (G1/4) standard
- Max operating pressure: 1.0 MPa
- Flow capacity: 850 L/min (Cv=1.2)
- Compatible voltage: Matched with mounted solenoid coils (DC12V-AC220V)
- Weight: 380g ±5%
- Dimensions: 54mm(W) × 45mm(H) × 90mm(L)
- Body material: Reinforced PA66 with glass fiber
- Seal material: HNBR (Hydrogenated Nitrile) for high temperature resistance
- Temperature range: -10℃ to 120℃ (with HNBR seals)
- Mounting pattern: ISO 5599-1 standard modular interface
- Max stackable units: Up to 16 bases in series
- Response time: <20ms (with compatible valves)
Modular valve base engineered for high-density pneumatic control systems, featuring integrated silencer and dust-resistant exhaust ports. The staggered port design reduces pressure loss by 18% compared to conventional bases. Includes built-in mounting slots for DIN rail or direct panel installation.
- Multi-axis pneumatic actuator control in assembly lines
- Plastic injection molding machine valve clusters
- Textile machinery air circuit distribution
- Automated warehouse sorting systems
- Semiconductor wafer handling equipment
Installation protocol:
Apply 3-5Nm torque during manifold assembly. Use M4×12 stainless steel screws
for panel mounting. Always install end plates when creating multi-stack configurations
to prevent air leakage.
| Property | Property Value |
|---|---|
| sku | 3V200M1F |
