Airtac 3V-F Base 3V300M7F
The AirTAC Airtac 3V-F Base 3V300M7F is a genuine 3V-F manifold base manifold base for 7 stations on one shared air supply. A base is a machined block: it carries no coil and no solenoid, so the valves that sit on it are ordered separately.
- Valve type3/2-way (3-port, 2-position)
- Stations7
- Series3V-F manifold base
About the Airtac 3V-F Base 3V300M7F
Seven stations, one air supply. The 3V300M7F is a machined manifold block that carries seven 3/2 solenoid valves side by side, so a single feed line serves the whole bank instead of seven separate take-offs. Each station still feeds and vents on its own.
As a base it has no coil, no voltage and no electrical state - those belong to the valves you order separately to fill it. It is a genuine AirTAC part, and we will confirm the base and valve datasheet figures for you on request.
Airtac 3V-F Base 3V300M7F Technical Specifications
| Model | Airtac 3V-F Base 3V300M7F |
|---|---|
| Series | 3V-F manifold base |
| Item form | Manifold base (no coil, no solenoid, no initial state) |
| Stations | 7 |
| Port size | Confirm from the datasheet — ask us |
| Thread | PT |
| Operating pressure | Confirm from the datasheet — ask us |
|---|---|
| Flow coefficient | Confirm from the datasheet — ask us |
| Temperature | Confirm from the datasheet — ask us |
| Protection | Confirm from the datasheet — ask us |
Model Code: Airtac 3V-F Base 3V300M7F
| 3V-F manifold base | Body. |
|---|---|
| 7F | 7 stations in one assembly. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V-F Base 3V300M7F Is Used
Sorting line diverters
Switch the air diverter cylinders along a parcel sorting line from one manifold mounted beside the conveyor.
Machine tool fixture clamps
Feed the clamp circuit of a CNC fixture with compact 3/2 valves mounted together on a single block.
Solenoid wiring consolidation
Replace a loom of individually plumbed and wired valves with one harness running along a shared manifold.
Is the Airtac 3V-F Base 3V300M7F the Right Part?
A manifold earns its keep on wiring as much as on air: DIN-plug valves share one tidy loom, and flying-lead variants reach the same block without extra adapters - the entry style is your choice when ordering the valves. Match each coil voltage to the panel supply, because a coil cannot be rewired to another voltage. Sizing each station to its actuator needs flow figures that are not in our hands for this family, so ask us to confirm the match before you order - or choose the documented AirTAC 3V2 or 3V3 bodies, where flow and coil power are published. A double-acting cylinder needs a 5-port AirTAC 4V valve, not any 3/2.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V-F Base 3V300M7F FAQ
This page is configuration only. We confirm pressure, flow and coil-power figures from the AirTAC datasheet when you send the RFQ. If you need numbers published on the page itself, the AirTAC 3V2 and 3V3 valve bodies are the documented alternatives.
Normally closed valves give no air at the outlet until energised, so the circuit vents safely on power loss. Normally open valves keep feeding the outlet when de-energised. Decide per station: fail-safe actuation wants NC, while a process that must keep blowing or clamping through a fault wants NO.
